Contents 1. Caution 2. Main Features 3. Controls & Functions 4. Menu Tree & Adjustment 5. Menu Operations [1] PICTURE [2] VIDEO [3] MARKER [4] REMOTE [5] LAYOUT [6] SYSTEM 6. Other Functions 7. DVI Support Resolution 9. Optional Accessories Multi Format LCD Monitor 3...
If any of the following conditions occurs, AC 100 ~ 240V (1.6A/50~60Hz) unplug the power cord from the AC outlet, DC 24V [Typ. 3.2A / LQM-241W ONLY] and request a qualified service person to perform repairs. All operating instructions must be read and a.
Page 5
1. Caution When mounting the product on a wall or When relocating the product placed on a cart, ceiling, be sure to install the product it must be moved with the utmost care. according to the method recommended by Sudden stops, excessive force and uneven the manufacturer.
AC/DC compatible requires no other accessory, for optimized - The product is powered by normal AC space utilization. source, but also 24V DC(LQM-241W) Multi screen display with individual control Additional features - Picture and color settings of each screen can - Wide Viewing Angle, Active Loop Through be controlled individually.
3. Controls & Functions LQM-241W : FRONT TALLY MENU DOWN/BRIGHT UP/CONTRAST ENTER/VOLUME ANALOG POWER MODE POWER INDICATOR QUAD CHROMA/PHASE/SCREEN SEL. BLUE ONLY/MONO H/V DELAY MARKER ASPECT SCAN LQM-471W : REAR REMOTE Factory PGM 1 RS-422 IN Factory PGM 2 RS-422 OUT...
Page 8
3. Controls & Functions LQM-471W : FRONT POWER ANALOG INPUT POWER INDICATOR ENTER/VOLUME MODE UP/CONTRAST QUAD DOWN/BRIGHT SCAN ASPECT MENU CHROMA/PHASE/SCREEN SEL MARKER H/V DELAY BLUE ONLY/MONO LQM-471W : REAR RS 422 IN RS 422 OUT AUDIO OUT AUDIO IN REMOTE HDMI(HDCP) FACTORY PGM 1...
Page 9
3. Controls & Functions FRONT [ANALOG] Button/Lamp [H/V DELAY] Button/Lamp - Used to select the desired Analog input and - Used to check horizontal sync and vertical DVI input. Press the button to activate the sync simultaneously by moving the display to analog input menu selection, then use UP and the left, right, up and down.
Page 10
3. Controls & Functions FRONT [MENU] Button [OPERATE] Lamp - Used to activate the OSD menu. - Indicates condition and power status of the monitor. - The lamp turns off when the power is [DOWN/BRIGHT] Button disconnected. - Used to move within the menus during OSD - Standby mode is indicated by a red LED light menu activation and is also used to decrease when the power is connected.
Page 11
[RS422 IN/OUT] (RJ-45) ~ AC IN - Used to control the monitor with protocol - 100 ~ 240V AC 50/60Hz provided by TVLogic or to support TSL protocol. DC 24V IN - 24V DC [FACTORY PGM1/2] (D-SUB 15 pin) - Factory program port for firmware updates and color calibration.
Below is the organization of the 3. After selecting a sub-menu, press ENTER products’s menu button to select an item with UP/DOWN button. PICTURE 1/2 PICTURE 1/2 LQM-241W LQM-241W TVLogic TVLogic 4. Press ENTER button to select the desired item. BRIGHT BRIGHT (The selected sub-menu will be highlighted.)
5. Menu Operations [2] VIDEO BIAS RED COLOR LQM-241W TVLogic - Used to adjust black level to control red COLOR TEMP 6500K color. GAIN RED - The value is selectable between -50 and 50. GAIN GREEN - Adjusts red color of dark section.
5. Menu Operations [3] MARKER FIT MARKER MARKER 1/2 LQM-241W TVLogic - Used to activate the FIT MARKER function. MARKER - With FIT MARKER “ON”, the safety area is CENTER MARKER displayed relative to the marker in use. SAFETY AREA With FIT MARKER “OFF”, the safety area is...
Page 16
5. Menu Operations [3] MARKER MARKER 2/2 LQM-241W TVLogic USER MARKER H1 USER MARKER H2 USER MARKER V1 USER MARKER V2 SDI-A 1080/59.94i USER MARKER H1 - Used to control the position of the first user defined horizontal marker line.
5. Menu Operations [5] LAYOUT LAYOUT LQM-241W TVLogic LAYOUT LQM-241W TVLogic SCREEN SELECT ALL SCREEN SCREEN SELECT ALL SCREEN BORDER COLOR WHITE BORDER COLOR WHITE BORDER THICKNESS BORDER THICKNESS WAVEFORM / VECTOR WAVEFORM WAVEFORM / VECTOR WAVEFORM WAVEFORM TYPE NORMAL...
5. Menu Operations [6] SYSTEM AUDIO VOLUME SYSTEM 1/3 LQM-241W TVLogic - Used to control the embedded audio output SET DEFAULT volume for the internal speakers and [AUDIO USER CONFIG SET USER1 OUT] terminal on the rear of the monitor.
Page 20
KEY LED - Used to set the ID of each monitor for the - Used to control key LED On/Off. TVLogic control protocol or DYNAMIC UMD - If the button with LED is pressed with the using RS-422/485 communication. KEY LED Off, LED comes on but goes off after 5 - Four consecutive IDs are available for seconds later.
Page 21
5. Menu Operations [6] SYSTEM KEY LOCK SYSTEM 3/3 LQM-241W TVLogic - This item locks all buttons on the front AUDIO LV METER G1 + G2 panel except power, input select, and menu AUDIO LV METER DISPLAY PAIR buttons. AUDIO LV METER REFERENCE...
6. Other Functions [1] ANALOG [2] MODE Button This product is capable of processing all Used to select SDI A/B/C/D input mode. input signals usable in ANALOG mode. The Select SDI input in single screen mode, ANALOG input settings are as follows: or select a screen first by pressing Screen Select button in multi screen mode to select 1.
Page 23
6. Other Functions [3] QUAD Button Used to select different multi display Waveform control in [LAYOUT] menu is modes. only available in 2P:2W and 1P:2W modes. Press this button to activate the modes. Waveform and Vectorscope can be The mode is changed as the following selected by controlling Waveform/Vector in sequence : QUAD, 2P:2W, 1P:2W, 1P:2P, 2P:2W mode.
Page 24
6. Other Functions [4] SCAN Button (Single Mode) This product supports various scan - ZERO SCAN : Zooms in/out of the image modes. without changing the aspect ratio. Press [SCAN] button on the front of the - UNDER SCAN : Zooms in/out of the image monitor to activate different scan modes.
Page 25
6. Button Functions [5] ASPECT [6] SCREEN SEL BUTTON 1. Four different aspect modes are available. Used to select single screen in multi When input signal is SDI or COMPONENT: screen mode. 1) 4:3 mode : Cuts left and right of the original image to fit to 4:3 aspect ratio.
Page 26
6. Other Functions [7] INPUT LIMIT FOR ANALOG (PBP MODE) 1. There is a limitation for Analog input in Multi 3. For example, if a COMPOSITE1 is selected on Mode. (No limitation for SDI signals) SCREEN 2, and if you wish to display COMPOSITE 2 on SCREEN 1, then the COMPOSITE 1 on 2.
7. DVI Support Resolution DVI ANALOG / DIGITAL SUPPORT RESOLUTION (LQM-241W) DVI-ANALOG mode supports the following modes : Resolution Frequency 640 X 480 60Hz, 75Hz 720 X 400 70Hz 800 X 600 60Hz, 72Hz, 75Hz 1024 X 768 60Hz, 70Hz, 75Hz...
Page 28
7. DVI Support Resolution DVI ANALOG / DIGITAL SUPPORT RESOLUTION (LQM-471W) DVI-ANALOG mode supports the following modes : Resolution Frequency 640 X 480 60Hz, 75Hz 720 X 400 70Hz 800 X 600 60Hz, 72Hz, 75Hz 1024 X 768 60Hz, 70Hz, 75Hz 1366 X 768 60Hz / 75Hz 60Hz / 75Hz...
Page 29
8. Product Specifications LQM-241W Size 24” Resolution 1920 X 1080 (16:10) Pixel Pitch 0.2705(H) X 0.270(W) mm Color Depth 16.7M (True 8bit) Viewing Angle H: 176degrees / V: 176degrees Luminance of white 500 cd/ m Contrast Ratio 1000 : 1 Display Area 518.4(H) X 324.0(V) mm...
Page 30
8. Product Specifications LQM-471W Size 47” Resolution 1920 X 1080 (16:10) Pixel Pitch 0.5415(H) X 0.5415(W) mm Color Depth 1.06Billion Colors (Dither 10bit) Viewing Angle H: 176degrees / V: 176degrees Luminance of white 500 cd/ m Contrast Ratio 1300 : 1 Display Area 1039.68(H) X 584.82(V) mm Input Connector...
Page 36
FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.tv 12F, ACE HIGH-END 8, 345-4 Gasan-dong, Geumcheon-gu, Seoul, 153-802, KOREA TEL : +82-70-8668-6611, FAX : 82-2-6123-3201, E-mail : sales@ t vlogic.co.kr...
