Contents 1. Caution 2. Main Features 3. Controls & Functions 4. Menu Tree & Adjustment 5. Menu Operations [1] PICTURE [2] VIDEO [3] COLOR [4] DISPLAY [5] GPI [6] MARKER [7] WAVEFORM [8] AUDIO [9] SYSTEM 6. Other Functions 7. DVI Support Resolution 8.
1. Caution Always use set voltage. If any of the following conditions occurs, • ● AC 100 ~ 240V (1.6A/50~60Hz) unplug the power cord from the AC outlet, ● XVM-175W : DC 12V (MAX 3.5A) and request a qualified service person to ●...
Page 5
1. Caution • When mounting the product on a wall or • When relocating the product placed on a ceiling, be sure to install the product cart, according to the method recommended by it must be moved with the utmost care. the manufacturer.
3. Controls & Functions XVM-175W : FRONT XVM-175W : REAR REMOTE RS 232 RS422 IN RS-422 OUT CVBS1/Y/G/S-Y CVBS2/Pb/B CVBS3/Pr/R-S-C DVI-I HDMI SDI-A SDI-B EXT.SYNC AUDIO IN ~AC IN DC 12V IN Multi Format LCD Monitor 7 XVM-175W_245W-N_325W-EN_V2.4.indd 7 2014-02-12 오후 5:36:...
Page 8
3. Controls & Functions FRONT : XVM-175W [STANDBY] lamp [SCAN] button/lamp ● ● - It affords power supply, which may be - Used to change the Scan mode. The mode is indicated by indication lamp. The lamp is changed as the following sequence. RED during power supply and GREEN during OVER SCAN ->...
Page 9
3. Controls & Functions FRONT : XVM-175W [F1] (In Single Mode) button/lamp [MENU/EXIT] button ● ● - This Functions button is used to activate the - Used to activate the OSD menu. feature selected in “System- KEY FUNCTION - When the OSD menu is activated, press this 1 ”...
Page 10
3. Controls & Functions XVM-245W-N : FRONT XVM-245W-N : REAR REMOTE RS422 IN RS 232 RS422 OUT CVBS1/Y/G/S-Y CVBS2/Pb/B CVBS3/Pr/R-S-C HDMI DVI-A SDI-A SDI-B EXT.SYNC AUDIO IN DC 24V IN ~AC IN 10 Multi Format LCD Monitor XVM-175W_245W-N_325W-EN_V2.4.indd 10 2014-02-12 오후 5:36:...
Page 11
3. Controls & Functions XVM-325W : FRONT MARKER SCAN MENU DOWN ENTER LED INDICATOR POWER ANALOG SDI A PHONE JACK SDI B CONTRAST BRIGHT APERTURE XVM-325W : REAR RS422 IN RS422 OUT ANDIO IN REMOTE HDMI AC/IN RS-232 EXT.SYNC IN/OUT...
Page 12
3. Controls & Functions FRONT : XVM-245W-N, XVM-325W [VIDEO] lamp [F1] (In Single Mode) button/lamp ● ● - Used when COMPOSITE INPUT is selected. - This Functions button is used to activate the feature selected in “System- KEY FUNCTION [S-VID] lamp 1 ”...
Page 13
3. Controls & Functions FRONT : XVM-245W-N, XVM-325W [SCAN] button/lamp [STANDBY] lamp ● ● - Used to change the Scan mode. The mode is - It affords power supply, which may be changed as the following sequence. indicated by indication lamp. The lamp is OVER SCAN ->...
Page 14
COMPOSITE 2, RGB B and [RS422 IN/OUT] (RJ-45) ● COMPONENT Pb signals. - Used to control the monitor with protocol provided by TVLogic or to support TSL [CVSBS3/Pr/R/S-C] (BNC) protocol. ● - Signal input terminal used to feed the...
4. Menu Tree & Adjustment [1] Menu Tree [3] Menu Control Sequence The product may be controlled and set 1. Press MENU button to activate the OSD ● menu system-wise through OSD displayed on on the screen. the screen. 2. Move to a desired sub-menu with the UP/ SDI A XVM-175WD DOWN button.
5. Menu Operations [1] PICTURE SDI A XVM-175WD SDI A XVM-175WD PAGE I >> PAGE II PAGE II >> PAGE I BRIGHT FOCUS ASSIST LEVEL FOCUS ASSIST COLOR CONTRAST CHROMA PHASE GREEN APERTURE BLUE NTSC SETUP 7.5IRE USER ASPECT H VGA H POSITION USER ASPECT V VGA V POSITION...
Page 17
5. Menu Operations [2] VIDEO SDI A XVM-175WD 3G FORMAT ● - Used to select input format of SDI 3G A/B DITHERING FILTER support(NORMAL MODE, A 444 10BIT_YCbCr, FAST MODE A 444 10BIT_RGB, A 444 12BIT_YCbCr, A FORCE psf 444 12BIT_RGB, A 422 12BIT_YCbCr, B 444 FILM MODE DETECTION 10/12BIT_YCbCr, B 444 10/12BIT_RGB, B 422 SDI FORMAT...
Page 18
5. Menu Operations [3] COLOR SDI A XVM-175WD BIAS RED ● - Used to adjust black level to control red PAGE I >> PAGE II COLOR TEMP 6500K color. GAIN RED - The value is selectable between Min(-50) and GAIN GREEN MAX(50).
Page 19
5. Menu Operations [3] COLOR SDI A XVM-175WD SD COLOR SPACE ● - Auto Color Space selection mode for SD PAGE II >> PAGE I BACKLIGHT signal input. COLOR SPACE REC-709(sRGB) HD COLOR SPACE REC-709(sRGB) GAMMA CURVE SD COLOR SPACE REC-709(sRGB) ●...
Page 20
5. Menu Operations [4] DISPLAY SDI A XVM-175WD SDI A XVM-175WD PAGE I >> PAGE II PAGE II >> PAGE I HD DIPLAY MODE 16:9 SCREEN SELECT ALL SCRREN TIME CODE ENABLE BORDER COLOR WHITE ORBITER CIRCUIT BORDER THICKNESS CLOSED CAPTION 608 CHANNEL SELECT CHANNEL 1 708 SERVICE SELECT...
Page 21
5. Menu Operations [5] GPI SDI A XVM-175WD Menu PAGE I >> PAGE II GPI 1 ANALOG CHNNEL Classifi- Settable Values GPI 2 SDI-A CHANNEL cation GPI 3 SDI-B CHANNEL GPI 4 PBP CHANNEL GPI 5 TALLY R NONE, ANALOG CHANNEL, SDI-A GPI 6 TALY G CHANNEL, SDI-B CHANNEL, PBP...
Page 22
- Available colors are RED, GREEN and - Used to set the ID of each monitor for the YELLOW. TVLogic control protocol or DYNAMIC UMD - B0:0 B1:0 / B0:1 B1:0 / B0:0 B1:1 / B0:1 B1:1 using RS-422/485 communication.
Page 23
5. Menu Operations [5] GPI <Dynamic UMD Protocol (TSL V3.1)> * Transmission (18 Byte) (PC or Device -> Monitor) HEADER CONTROL DISPLAY DATA (1 BYTE) BYTE(1 BYTE) (16 BYTE) * [HEADER] : Display address (0~126) + 80 hex. * [CONTROL BYTE] bit 0 : Tally 1 (1=on, 0=off) bit 1 : Tally 2 (1=on, 0=off) bit 2 : Tally 3 (1=on, 0=off)
Page 24
5. Menu Operations [5] GPI Tally Type - Default ● - S-8C(Single 8 Character) & S-16C(Single 16 Character) Bit 1 Bit 1 Operation (Tally2) (Tally1) CHANNEL1 CHANNEL1 CHANNEL1 CHANNEL1 - D-8C(Dual 8 Character) Bit 1 Bit 1 Operation (Tally4) (Tally3) CHANNEL1 CHANNEL1 CHANNEL1...
Page 25
5. Menu Operations [5] GPI SDI A XVM-175WD SDI A XVM-175WD PAGE IV >> PAGE I PAGE III >> PAGE IV PASSWORD UMD FONT SIZE NORMAL IP ADDRESS 192.168.123. UMD FONT TYPE FONT 1 SUBNET MASK 255.255.128. GATEWAY PORT NO 10262 REMOTE CONTROL ETHERNET...
Page 26
5. Menu Operations [6] MARKER SDI A XVM-175WD FIT MARKER ● - Used to activate the FIT MARKER function. PAGE I >> PAGE II MARKER - With FIT MARKER “ON”, the safety area is CENTER MARKER displayed relative to the marker in use. SAFETY AREA With FIT MARKER “OFF”, the safety area is FIT MARKER...
Page 27
5. Menu Operations [6] MARKER [7] WAVEFORM SDI A XVM-175WD SDI A XVM-175WD PAGE II >> PAGE I PAGE I >> PAGE II USER MARKER H1 WAVEFORM/VECTOR USER MARKER H2 WAVEFORM INTENSITY USER MARKER V1 WAVEFORM TRANS OPAQUE USER MARKER V1 VECTOR GAIN x4 LINE WAVEFORM ENABLE LINE POSITION POSITION...
Page 28
5. Menu Operations [7] WAVEFORM SDI A XVM-175WD LINE SELECT POSITION ● - In WAVEFORM/VECTOR, use the Up/Down PAGE I >> PAGE II WAVEFORM/VECTOR button to select User’s desired line. WAVEFORM INTENSITY WAVEFORM TRANS OPAQUE LINE SELECT DRAW VECTOR GAIN x4 ●...
Page 29
5. Menu Operations [7] WAVEFORM SDI A XVM-175WD Y PICTURE BLINK ● - Used to set selections of image that exceeds PAGE II >> PAGE I RANGE EROR Y MAX and Y MIN to blink. Y MAX Y MIN C PICTURE BLINK C MAX ●...
Page 30
5. Menu Operations [8] AUDIO LEVEL METER POSITION SDI A XVM-175WD ● - Used to control the position of the Audio LEVEL METER SELECT LEVEL METER DISPLAY PAIR Level Meters. LEVEL METER REFERENCE -20dB - Available values are HOR, VER and BOT. LEVEL METER DECAY TIME *16 CH(HOR.): Displays each 8 channel audio LEVEL METER SIZE...
Page 31
5. Menu Operations [9] SYSTEM INTERNAL PATTERN SDI A XVM-175WD ● - This item generates internal white pattern. PAGE I >> PAGE II USER CONFIG SET USER 1 - The white level select between 0% and 100% LOCK NUMBER XVM000000 (Per 5% increase or decrease) LOCK ENABLE --------...
Page 32
5. Menu Operations [9] SYSTEM KEY FUNCTION 5 (XVM-175W only) SDI A XVM-175WD ● - User can select the function for [F4] button. PAGE II >> PAGE I KEY LED - Selectable Items : ASPECT, H/V DELAY, KEY FUNCTION 1 ASPECT FREEZE, WAVEFORM, TIMECODE, CC SEL, KEY FUNCTION 2...
Page 33
5. Menu Operations [9] SYSTEM SDI A XVM-175WD PAGE III >> PAGE I BOARD VERSION 0101 1306 4.00 9 MAIN PBP1 PBP2 BRIG CONT KEYPAD VERSION COLOR : 6500K 6500K 6500K MCU VERSION SCAN ZERO OVER OVER FPGA VERSION GPU VERSION INFOMATION ●...
6. Other Functions [1] ANALOG This product is capable of processing all 2. Use the UP/DOWN button to select desired ● input source and press the ENTER button to input signals usable in ANALOG mode. confirm. The ANALOG input settings are as follows: 3.
Page 35
6. Other Functions [2] ASPECT [3] SCAN 1. Four different aspect modes are available. This product supports various scan modes. ● When input signal is SDI Press [SCAN] button on the front of the ● -A/B, Composite monitor to activate different scan modes. 1/2/3 and Input Signal Format is SD : 1) 4:3 mode : Cuts left and right of the original 1.
Page 36
6. Other Functions [3] SCAN 3. The following represents the different - 1:1 SCAN : 1:1 pixel mapping of original types of scan mode. When a scan mode is image. This feature is available only when selected, display skips the next mode if its the size of the original image is bigger than required condition is not met.
Page 37
6. Other Functions [4] PBP(Picture-by-Picture) 1. Press PBP button to activate the PBP 2. To control the individual image in multi function. Then the two images will be screen, use the Screen F1 displayed in the monitor. In Normal key to select Screen(when an individual screen is not desired display then control the desired selected in PBP mode), key function and OSD...
Page 38
6. Other Functions [5] INPUT LIMIT FOR ANALOG (PBP MODE) 1. There is a limitation for Analog input in PBP 3. For example, if a COMPOSITE1 is selected Mode. (No limitation for SDI signals) on SCREEN 2, and if you wish to display 2.
7. DVI Support Resolution DVI ANALOG / DIGITAL SUPPORT RESOLUTION DVI-ANALOG mode supports the following modes : ● Resolution Frequency 640 X 480 60Hz, 75Hz 720 X 400 70Hz 800 X 600 60Hz, 72Hz, 75Hz 1024 X 768 60Hz, 70Hz, 75Hz 1366 X 768 60Hz / 75Hz 1280 X 1024...
8. Product Specifications : XVM-175W Size 17” Resolution 1920 X 1080 Pixel Pitch 0.199(H) X 0.199(W) mm Color Depth 1.07B colors (True 10bit) Viewing Angle R/L, U/D 178degrees Luminance of white 300 cd/ m Contrast Ratio 800 : 1 Display Area 381.9(H) X 214.8(V) mm 1 X DVI-I DVI IN...
Page 41
8. Product Specifications : XVM-245W-N Size 24.1” Resolution 1920 x 1200 (16 : 10) Pixel Pitch 0.270(H) X 0.270(W) mm Color Depth 1.07B colors (True 10bit) Viewing Angle H : 178 degrees / V : 178 degrees Luminance of white 250 cd/ m Contrast Ratio 1000 : 1...
8. Product Specifications : XVM-325W Size 32” Resolution 1920 X 1080 Pixel Pitch 0.36375(H) X 0.36375(W) mm Color Depth 1.07B colors (True 10bit) Viewing Angle R/L, U/D 178degrees Luminance of white 500 cd/ m Contrast Ratio 1300 : 1 Display Area 698.4(H) X 392.85(V) mm...
Page 43
9. Optional Accessories RACK MOUNT ANY DISPLAY UP TO 24” 8.4 inch 9 inc h 7 inch 15 inch 17 inch 21 inch 24 inch Multi Format LCD Monitor 43 XVM-175W_245W-N_325W-EN_V2.4.indd 43 2014-02-12 오후 5:36:...
Page 44
FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.tv 12F, ACE HIGH-END 8, 84 Gasan digital 1-ro, Geumcheon-gu, Seoul, 153-802, KOREA 부사장 TEL : +82-70-8668-6611, FAX : 82-2-6123-3201, E-mail : sales@ t vlogic.co.kr 조 성 일 153-802 서울특별시 금천구 가산동 345-4 에이스하이엔드 8차 12층...
