Texas Instruments TMS320C2x User Manual page 155

ADDS
Add to Accumulator With Sign-Extension Suppressed
Syntax Direct:
Indirect:
Operands 0
0
Execution (PC) + 1
(ACC) + (dma)
(dma) is a 16-bit unsigned number.
Affects OV; affected by OVM.
Affects C.
Not affected by SXM.
Encoding
Direct:
Indirect:
Description The contents of the specified data memory location are added with sign-exten-
sion suppressed. The data is treated as a 16-bit unsigned number, regardless
of SXM. The accumulator behaves as a signed number. Note that ADDS pro-
duces the same results as an ADD instruction with SXM = 0 and a shift count
of 0.
Words 1
Cycles
4-32
[ label ] ADDS dma
[ label ] ADDS
dma 127
next ARP 7
PC
ACC
15 14 13 12 11 10
0 1 0 0 1 0
0 1 0 0 1 0
Cycle Timings for a Single Instruction
PI/DI PI/DE
1 2+d
Cycle Timings for a Repeat Execution
n 1+n+nd
{ind}[, next ARP ]
9 8 7 6 5
0 1
0 Data Memory Address
0 1 1 See Section 4.1
PE/DI PE/DE PR/DI
1+p 2+d+p
n+p 1+n+nd+p
Assembly Language Instructions
4 3 2 1 0
PR/DE
1 2+d
n 1+n+nd
