Chapter 2 - Hardware Installation

Board Layout

4-pin
Right Angle
(optional)
DC-in
4-pin Vertical Type (optional)
DDR4_2 SODIMM
ASMedia
ASM1442
DDR4_1 SODIMM
DVI-D
ASMedia
ASM1442
HDMI
USB 3.0
USB 3-4
USB 3.0
Mini PCIe 2
USB 1-2
Mini PCIe 1
LAN 1
Intel
WGI211AT
Socket LGA1151
LAN 2
S/PDIF
Front Audio
9
1
Auto Power-on
1
10
2
Select (JP1)
1
SD101-H110: 12V DC-in jack (default) or 4-pin power Right/Vertical Angle
Connector(optional).
SD103-H110: 15~36V DC-in jack (default) or 4-pin power Right/Vertical Angle
Connector(optional).
Chapter 2 Hardware Installation
Clear CMOS Data
(JP5)
1
1
2
6
ME Disable
1
5
1
SMBus
2
Battery
Intel
H110
USB 2.0
1
USB
USB
Chassis
7-8
5-6
Intrusion
10
9
10
9
SPI Flash
BIOS
2
1
2
1
1
SATA 3.0
System Fan 2
SATA 0
1
System Fan 1
1
1
1
SATA 3
SATA
Power
1 2
1
CPU Fan
Front
Panel
1
11 12
Digital
I/O Power
Digital
Standby
I/O
Power LED
Panel Power
1
2
Select (JP8)
5
6
1
1
Backlight
LCD/Inverter
Power
Power
Select
1
(JP6)
LCD/Inverter Power Select (JP7)
1
39
COM 1
RS232/Power
2
40
Buzzer
Select (JP2)
LVDS LCD Panel
2
6
2
10
2
10
2
10
2
10
1
5
1
9
1
9
1
9
1
9
COM 1
COM 2
COM 3
COM 4
Chapter 2
Important:
Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in
boards, and other components. Perform installation procedures at an ESD workstation
only. If such a station is not available, you can provide some ESD protection by wear-
ing an antistatic wrist strap and attaching it to a metal part of the system chassis. If
a wrist strap is unavailable, establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.

System Memory

Important:
When the Standby Power LED lights red, it indicates that there is power on the sys-
tem board. Power-off the PC then unplug the power cord prior to installing any de-
vices. Failure to do so will cause severe damage to the motherboard and components.
Features
Two 260-pin SODIMM up to 32GB
Dual Channel DDR4 1866/2133MHz
9
DDR4_2
DDR4_1
Standby
Power LED
www.dfi.com
