Troubleshooting Cat 6 & Cat 6a Structured Copper Cabling Systems
If a Category 6 cabling system does not meet the electrical requirements for supporting 10GBASE-T
applications, see the TSB-155 provides guidelines designed to mitigate the alien crosstalk between the
target pair and the disturbing pairs of Category 6 channels and permanent links. Annex B of TSB-155
outlines the following mitigation actions most appropriate for individual situations:
•
Use Category 6 shielded or Category 6a patch cords;
•
Replace Category 6 connectors with Category 6a connectors;
•
Use non-adjacent patch panel positions;
•
Separate equipment cords and patch cords;
•
Unbundle or more loosely bundle the horizontal cabling; and
•
Reconfigure the cross-connect as an interconnect.

Technical Specifications

The Transition Networks M/GE-ISW-SFP-01-PD was designed to meet these specifications.
Standards Compliance
Regulatory Compliance for Emission
Regulatory Compliance for Immunity
Safety Compliance
Power Consumption
Power Source
Size (width x depth x height)
Weight
Operating Temperature
Storage Temperature
Altitude
Operating Humidity
MTBF*
Warranty
CAUTION: Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485,
DS1, DS3, Video Coax, etc., are intended to be connected to intrabuilding (inside plant) link segments
that are not subject to lightening transients or power faults. Copper-based media ports are NOT to be
connected to interbuilding (outside plant) link segments that are subject to lightening transients or power
faults. Failure to observe this caution could result in damage to equipment.
WARNING: Visible and invisible laser radiation when open. Do not stare into the beam or view directly
with optical instruments. Failure to observe this warning could result in an eye injury or blindness.
WARNING: Use of controls, adjustments, or the performance of procedures other than those specified
herein could result in hazardous radiation exposure.
The information in this manual is subject to change. For the most up-to-date information, view the user's
guide on-line at www.transition.com
33668 Rev. A
IEEE 802.3-2012
EN55022 Class A
EN55024
NA
1.8W (47mA @ 37V PoE input)
IEEE 802.3af supplied through TP RJ-45
3.3 " x 1.8 " x 0.8 " (83.82 x 45.72 x 20.32 mm)
0.25 lb. (0.11 Kg.)
-40 to +75 deg. C
-40 to + 85 deg. C
0-10,000 feet
5% to 95% (non-condensing)
Greater than 225,000 MIL-HDBK-217F Hours.
Greater than 618,750 Bellcore Hours.
Prediction Method: MIL-HDBK-217F Parts Count.
Environment: GB, Ground Benign. Temperature 25°C.
Lifetime
and the click on Product/Product Finder.
http://www.transition.com/
M/GE-ISW-SFP-01-PD User Guide
Page 11 of 16
