Xilinx VC707 Getting Started page 9

Verify Jumpers are in Default Positions
Verify the jumpers on the VC707 board are positioned as shown in
for the location of the jumpers.
Table 1-1: Default Jumper Settings
Callout Jumper
1 J6 SFP Enable
2 J9 XADC GND ferrite filter bypass jumper
3 J10 XADC GND-to-XADC_AGND jumper
4 J11 TI Controller U42 Addr 52 Reset jumper
5 J12 TI Controller U43 Addr 53 Reset jumper
6 J13 USB Mini-B Connector J2 VBUS
7 J14 USB SMBC U8 CLKOUT selector
8 J38 SFP RX Rate: 1-2 = Full BW Rate, 2-3 = Low BW Rate
9 J39 SFP TX Rate: 1-2 = Full BW Rate, 2-3 = Low BW Rate
10 J42 XADC external 1.2V or internal VREFP selector
11 J43 XADC VCC Select Header
12 J44 USB Mini-B Connector J2 GND jumper
13 J45 USB SMBC U8 VBUS
14 J49 PCIe Bus Width Select Header
15 J50 TI Controller U64 Addr 54 Reset jumper
16 J51 FMC_VADJ_ON_B jumper
17 J53 XADC VCC5V0-to-XADC_VCC5V0 jumper
18 J54 XADC REF3012 U35 V
Getting Started with the VC707 Evaluation Kit
UG848 (v1.4.1) October 14, 2015
Function
Select
IN
www.xilinx.com
Preliminary Setup
Table 1-1. See Figure 1-6
Schematic
Default Jumper
0381418 Page
Position
Number
None 31
None 40
1–2 40
None 46
None 50
None 44
None 44
1–2 31
1–2 31
1–2 40
2–3 40
None 44
1–2 44
1-2 30
None 53
1–2 46
1–2 40
1–2 40
Send Feedback
9
