Helios Users Guide
10 Speaker (+) / or
Extra Analog Input
3 (-)
11 Analog 1
12 CAN High
13 Door Lock
14 Arm
15 RS232 RX
16 Door
* The odometer input informs the system whether to measure mileage by
counting odometer pulses or by calculating the distance traversed by the
vehicle using GPS. The odometer can count pulses from any type of pulse
generator.
www.starcomgpsglobal.com
Violet Audio
Yellow/Blue Input (+)
Black/Gray CAN Bus
connection
Gray/Orange Output (-)
Orange/White Input (-)
Blue/Black Communication
Green Input (-)
Hands Free Kit
connector. In case
HFK is not
connected, you can
cut the connector
and use pin 10 as
Extra Analog Input
3
Usually used for
fuel or temperature
measurement
CAN +
Install with an
external relay. See
Appendix C –
Central Locking
System
Configuration
RS232 wire set with
Molex connector
84
