Advantech PCA-6188 Startup Manual

PCA-6188 Full-sized PCI/ISA-bus socket 478
Pentium® 4/Celeron® processor-with ATI M10
VGA chip CPU card
Packing List
Before you begin installing your card, please make
sure that the following materials have been shipped:
• 1 PCA-6188 Pentium ® 4/Celeron processor-based
single board computer
• 1 PCA-6188 Startup Manual
• 1 CD with driver utility and manual (in PDF format)
• 1 FDD cable
• 2 Ultra ATA 66/100 HDD cables
• 2 Serial ATA HDD data cable
• 2 Serial ATA HDD power cable
• 1 ATX 12V power converter
cable
• 1 Printer (parallel) port & COM
port cable kit
• 1 Dual COM port cable kit
• 1 Y cable for PS/2 keyboard
and PS/2 mouse
• 2 Two USB port cable
• 1 VGA cable
• 1 DVI cable
• 1 Video Cable( S / Composite
terminal)
• Warranty card
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/readstep2.html
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/nc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCA-6188 series Rev. A1.
Part No. 2002618810
Printed in Taiwan
Specifications
Standard SBC Functions
• CPU: Intel® socket 478 Celeron® (Northwood) 2.0~2.8 GHz,
Pentium® 4 (Northwood/Prescott) up to 3.4 GHz, FSB 400/533/
800 MHz; suppports Intel Hyper-Threading technology. CPU with
1.75V core voltage (Willamete) not supported.
• BIOS: Award 4 Mb Flash memory BIOS
• Chipset: Intel 875P with 6300ESB
• System Memory: Dual Channel; Four 184-pin DIMM sockets
accepts up to 4 GB DDR 266/333/400 SDRAM (PC 2100/2700/
p/n: 1700340640
3200)
p/n: 1701400452
• SATA/IDE interface: Supports up to two independent Serial ATA
p/n: 1700071000
hard drives (up to 150MB/s) and two IDE hard disk drives or four
enhanced IDE devices. BIOS enabled/disabled.
p/n: 1703150102
• FDD interface: Supports up to two FDDs
p/n: 170304015K
• Serial ports: Two serial RS-232 ports
• Parallel port: One parallel port, supports SPP/EPP/ECP mode
p/n: 1701260305
• Keyboard/mouse connector: Supports one standard PS/2 key-
board and mouse
• Watchdog timer: 255 level timer intervals
p/n: 1701092300
• USB (2.0): Maximum up to four Universal Serial Bus ports
p/n: 1700060202
VGA Interface
p/n: 1700100170
• Chipset: ATi Mobility Radeon 9600 Pro (AGP 8X)
• Interface: AGP 8X
p/n:1700000259
• Display memory: 64MB DDR SDRAM integrated
p/n:1700000821
• Video Output :
p/n:1700000784
CRT1, 2048 x 1536, up to 200Hz vertical rate
CRT2, 2048 x 1536, up to 200Hz vertical rate
1 LVDS, dual 115MHz interface, 2048 x 1536@60Hz,
1 DVI, 1600 x 1200@60Hz, 165MHz 2
Ethernet Interface
• Chipset:
• Single 10/100/1000Base-T:Intel 82547GI (CSA)
• Dual 10/100/1000Base-T: Intel 82547GI (CSA) and Intel 82541GI
(PCI)
• Connection: On-board RJ-45 connector x 2
Mechanical and Environmental
• Dimensions (L x W): 338 x 122 mm
• Power supply voltage: +5 V ± 12 V
• Power requirements: Typical : +5V:7.32A, +12V:7.68A (Intel Pen-
tium® 4 3.06GHz with 533MHz FSB, 1GB DDR 333 SDRAM)
• Operating temperature: 0 ~ 60 °C (depending on CPU)
• Weight: 0.5 kg (weight of board)
1st. Edition
August 2004
PCA-6188 Startup Manual 1
