Advantech PCA-6155V Startup Manual

PCA-6155V Pentium
VGA & SSD
Startup Manual

Packing List

Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCA-6155V Socket 7 Pentium
based single board computer
• 1 FDD cable
• 2 UDMA 33 HDD cables
• 1 printer (parallel port) and COM port cable kit
• 1 ivory cable for PS/2 keyboard and PS/2 mouse
• 1 USB cable (optional)
• 1 PCA-6155V startup manual
• CD-ROM and manual (in PDF format)
• Warranty certificate
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: For detailed contents of the PCA-6155V,
please refer to the enclosed CD-ROM or disk
(in PDF format).
Note 2: Acrobat Reader is acquired to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/nc
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCA-6155V series Rev. A1
Part No. 2006615510
Printed in Taiwan
®
MMX SBC with
® MMX processor-
p/n: 1701340700
p/n: 1701400601
p/n: 1701260303
p/n: 1700060202
p/n: 1700100170
1st Edition
May 2001

Specifications

Standard SBC Functions
• CPU: Intel Pentium ® , Pentium MMX, AMD K5, AMD
K6, Cyrix M1, Cyrix MX, or IDT Win Chip C6
• BIOS: Award 128 KB (1 Mbit) memory; supports plug
and play
• Chipset: SiS5598
• L2 cache: On-board 512 KB synchronous (pipeline
burst) SRAM
• Green function: Features power management option
via BIOS, activated by keyboard or mouse activity.
Supports doze, sleep and suspend modes. APM 1.1
compliant
• Memory: -Two 72-pin SIMM sockets. Support 32-bit
FPM or EDO DRAM with memory capacity
from 2 ~ 128 MB.
-Two 168-pin DIMM sockets. Support 64-bit
3.3 V SDRAM with memory capacity from
8 ~ 256 MB.
• EIDE interface: Handles up to two IDE HDDs or
other IDE devices. Supports PIO mode 4 and Ultra
DMA mode
• FDD interface: Supports up to two floppy disk drives
• Parallel port: Configured to LPT1, LPT2, LPT3 or
disabled. Supports multi-mode parallel port (SPP/
ECP/EPP)
• Serial ports: Two 16C550 UARTs, one RS-232, one
RS-232/422/485 interface
• Watchdog timer: Can generate a system reset or
IRQ 11. Software enabled/disabled. Time interval is
from 1 to 62 seconds, jumperless with run-time setup
• Keyboard/mouse connector: 6-pin mini-DIN
connector on the mounting bracket eases
connection to a keyboard or PS/2 mouse.
An on-board keyboard pin header connector is also
available
• I/O bus expansion: PC/104 connector with face-up
installation
• USB interface: Two USB connectors with fuse
protection. Complies with USB specification 1.0
Solid State Disk
• Supports DOC 2000 up to 144 MB
PCA-6155V Startup Manual 1
