PART LIST—Model No.PFIVEL32011.0
Item Description
1 Main frame
2 Handlebar post
3 Front stabilizer
4 Rear stabilizer
5 Pedal support (L/R)
6 Swing bar(L/R)
7 Handlebar (L/R)
8 Armrest
9 Computer
10 Pedal (L/R)
11 Front end cap
12 Carriage bolt M10X57
13 Arc washer Φ10 X1.5XΦ25XR28
14 Acorn nut M10
15 Rear end cap
16 Allen screw M8X16
17 Tension controller
18 Extension wire
19 Tension cable
20 Sensor wire
21 Cross screw M5X45
22 Crank
23 Nut cap S14
24 Hex bolt M8X15
25 Flat washer Φ8.2XΦ32 X2
26 Axle bushing Φ32 X2.5
27 Long axle
28 Round end cap Φ28 X1.5
29 Square end cap 40X25X1.5
30 Hex bolt M8X55
31 Flat washer d8 X1.5
32 Nylon nut M8
33 Hex bolt M10X45
34 Flat washer d10X1.5
35 Nylon nut M10
36 Nut cap S16
37 Hex bolt M10X50
38 Pedal locking bolt (L/R)
39 Axle bushing Φ24 X20XΦ16.1
40 Connecting joint (L/R)
41 Spring washer Φ13 XB2
42 Nylon nut (L/R)
43 Nut cap S19
44 Arc washer Φ20 Xd8X2XR16
45 Carriage bolt M8X40
46 Mushroom end cap
47 Handlebar foam grip
48 Armrest foam grip
49 Round end cap Φ25X1.5
Qty. Item Description
1 50 Pulse sensor wire
1 51 Hex bolt M8X30
1 52 Spring washer D8
1 53 Handlebar chuck cover
2 54 Flat washer D4
2 55 Cross screw M4X12
2 56 Arc washer Φ20Xd8.5XR25
1 57 Nut cap S13
1 58 Acorn nut M8
2 59 Flat washer D5
2 60 Tension controller cover
4 61 Metal bushing Φ14X10XΦ10.1
4 62 Waveform washer D17X0.3
4 63 Crossing tapping screw ST3X10
2 64 Waveform washer Φ20XΦ28 X0.3
4 65 Small plastic cover
1 66 Chain cover
1 67 Hex nut
1 68 Washer
1 69 Nut
1 70 Ball rack
1 71 Bottom bracket cup
4 72 Tri-slot nut
2 73 Big washer
2 74 Belt tray
6 75 Round magnet
1 76 Belt
2 77 Screw
4 78 Hex bolt M6x15
2 79 Spring washer D6
2 80 Washer D6x1
2 81 Spring washer D12
4 82 Magnetic board axle
6 83 Magnetic board
6 84 Square magnet
4 85 Spring
2 86 Hex nut M5
2 87 Hex bolt M5x60
4 88 Sensor
2 89 Hex nut M10x1
2 90 Hex nut M6
2 91 U-shaped washer
2 92 Bolt M6x50
4 93 Thin nut M10x1
4 94 SpancerΦ10XΦ14x22
2 95 Bearing 6000z
2 96 Flywheel
2 97 Flywheel axle
2
14
Qty.
2
2
4
1
2
2
4
2
4
1
1
4
2
4
2
2
2
1
1
1
2
2
1
1
1
1
1
6
2
2
2
2
1
1
8
1
2
1
1
2
2
2
2
2
1
2
1
1
