MP2800 Series Router
Installation Manual
Version 1.0
Maipu Communication Technology Co., Ltd
No. 16, Jiuxing Avenue
Hi-tech Park
Chengdu, Sichuan Province
People's Republic of China - 610041
Tel: (86) 28-85148850, 85148041
Fax: (86) 28-85148948, 85148139
URL: http://
www.maipu.com
Email:
overseas@maipu.com
Maipu Confidential & Proprietary Information
Page 1 of 55
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Maipu MP2801
Summary of Contents for Maipu MP2801
- Page 1 MP2800 Series Router Installation Manual Version 1.0 Maipu Communication Technology Co., Ltd No. 16, Jiuxing Avenue Hi-tech Park Chengdu, Sichuan Province People’s Republic of China - 610041 Tel: (86) 28-85148850, 85148041 Fax: (86) 28-85148948, 85148139 URL: http:// www.maipu.com Email: overseas@maipu.com Maipu Confidential &...
-
Page 2: Document History
Maipu makes no representations or warranties with respect to this document contents and specifically disclaims any implied warranties of merchantability or fitness for any specific purpose. Further, Maipu reserves the right to revise this document and to make changes from time to time in its content without being obligated to notify any person of such revisions or changes. -
Page 3: Maipu Feedback Form
Maipu Feedback Form Your opinion helps us improve the quality of our product documentation and offer better services. Please fax your comments and suggestions to (86) 28-85148948, 85148139 or email to overseas@maipu.com. Document Title MP2800 SERIES ROUTER INSTALLATION MANUAL VERSION 1.0 Product... -
Page 4: Table Of Contents
2-port Switch IP Phone Module (2VOS) ..................29 Ethernet Module (ETE) Series ................30 1-port Ethernet Module (1ETE) ....................30 ISDN S/T Module (ST) Series ................. 31 11-port ISDN S/T Module (1ST) .....................31 Maipu Confidential & Proprietary Information Page 4 of 55... - Page 5 Module Installation Steps .......................47 Module Interface Cable Connection ..................48 Cables ...................... 53 Ethernet Interface Cable ..................53 Console Port Cable ....................54 RM2-1E1 & RM2-1CE1 Using RJ45-RJ45 Crossing Twisted-pair ......... 55 Maipu Confidential & Proprietary Information Page 5 of 55...
-
Page 6: Router Installation Manual
Maipu English documentation and products. Customer Support If you have problems or questions regarding your product, please contact us by e-mail at overseas@mail.maipu.com. You can also call our Overseas Business Department over +86–28-85148850, 85148041, 85148050, 85148750, and 85148997. Documentation Support Maipu Communication Technology Co., Ltd welcomes comments and... -
Page 7: Overview
The series provides backup schemes and QoS features. It can be applied to multiple services such as data, video and voice. The router series, combined with other Maipu routers, provides complete WAN network solutions for operator, finance, government, energy sources, traffic,... -
Page 8: Key Features
Supports secure access control and compatible with products of main manufacturers Compatible with the routers of the main manufacturers in the industry, which protects the original device investments and the reliable running of the whole network. Maipu Confidential & Proprietary Information Page 9 of 55... -
Page 9: Features
Then users and manufacturers can maintain devices anywhere via telephone line dial-up to realize “Zero-spot service”. MP2800 supports Maipu intelligent NMS for diagnosing and fixing router faults, automatically generating a record for users to query. In this way, it reduces management and maintenance work of users considerably. - Page 10 VPN networks from Layer 2 to Layer 3. When branch offices are inter- connected by various lines, multiple services can be born on a single physical network to ensure the security and save cost. Maipu Confidential & Proprietary Information Page 11 of 55...
-
Page 11: Hardware
The optimized structural design has the features of anti-quake, anti high and low temperature, anti electromagnetic radiation and easy to assemble and disassemble, which makes the device work stably and reliably. Hardware MP2800 Appearance Maipu Confidential & Proprietary Information Page 12 of 55... -
Page 12: Mp2800 Front Panel
Off: 10M ACT - Ethernet interface data receiving/sending indicator LAN Ethernet 0—23 Yellow (left): 10/100M Ethernet interface data rate indicator On: 100M Off: 10M Green (right): Ethernet interface data rate indicator Maipu Confidential & Proprietary Information Page 13 of 55... -
Page 13: Mp2800 Router Back Panel
MP2800 Series Router Installation Manual Version 1.0 MP2800 Router Back Panel MP2800 series router back panel interface configuration Maipu Confidential & Proprietary Information Page 14 of 55... - Page 14 8AX and 1STA modules can be inserted. The multi-functional slots adopt modular design. Users can select different interface cards and the corresponding software modules as desired. • 1ETE modules are supported only by multi-functional slots S0 and S1. Maipu Confidential & Proprietary Information Page 15 of 55...
-
Page 15: Mp2800 Series Router System
Maximum weight 5.7KG Power supply input AC: 100-240V，50/60Hz voltage AC: -40V--57V Environment 0-40℃ temperature Environment humidity 10-90%, Non-condensing Power supply rating power 27W±10% (MP2804) Maximum power 35W±10% (MP2806) 42W±10% (MP2816) 52W±10% (MP2818) Maipu Confidential & Proprietary Information Page 16 of 55... -
Page 16: Functions
CALLBACK Dial-on-demand Dialup backup Routing protocol Static routing Dynamic routing: RIPv1 RIPv2 OSPF IS-IS IRMP Policy routing Multicast: IGMP PIM-SM PIM-SSM PIM－DM DVMRP Hot backup: VRRP VBRP (compatible with CISCO HSRP) Maipu Confidential & Proprietary Information Page 17 of 55... - Page 17 Colorful debugging information support Support log function Security IP packet filter firewall Configuration command protect ensures that unauthorized users cannot invade the router. PAP/CHAP RADIUS TACACS IPSEC data encryption 802.1x L2TP Maipu Confidential & Proprietary Information Page 18 of 55...
-
Page 18: Modules
For sync port, 2.048Mbps in DCE mode and 8 Mbps in DTE mode. For async port, 115.2Kbps. The working mode by default is in sync mode. In DTE mode, it uses clock from external DCE equipment such as external Maipu Confidential & Proprietary Information Page 19 of 55... - Page 19 Tie-in DB25-DB25 DB25-DB25 Interface standard & working V.24 V.35 EIA/TIA-232 mode Minimum BR (bps) 1200 1200 Maximum BR (bps) 128K 115.2K Protocol & Service Dialup HDLC Backup HDLC SLIP SLIP LAPB Maipu Confidential & Proprietary Information Page 20 of 55...
-
Page 20: Channelized E1 Module (Ce1) Series
1-port channelized E1 module (1CE1) indicator: Lost indicator On: Cannot check sync signal Off: After sync 1 CE 1 Mo d ul e Connected C able Coaxial line with BNC pin and RJ45-RJ45 connected twisted-pair. Maipu Confidential & Proprietary Information Page 21 of 55... -
Page 21: Non-Channelized E1 Module (E1) Series
2M transparent transmissions. 1 E 1 M o d u l e & I n d i c a t o r 1E1 module: 1-port non-channelized E1 module (1E1) Maipu Confidential & Proprietary Information Page 22 of 55... -
Page 22: Frequency-Band Modem M336 Series
The modem can serve as the caller and callee. In sync mode, the clock mode includes internal clock, external clock and sub clock; the async mode includes direct async, buffer async, and error async. Maipu Confidential & Proprietary Information Page 23 of 55... - Page 23 1M336 Interface Attri butes 1M336 interface attributes: 1-port 33.6K frequency-band MODEM (1M336) attributes: Attributes Description Tie-in RJ45 Number of interfaces Supported link protocol Frame relay X.25 HDLC Supported network protocol Maipu Confidential & Proprietary Information Page 24 of 55...
-
Page 24: Isdn (U) Series
1 U M o d u l e C o n n e c t e d C a b l e 1U module connected cable is RJ45 (4, 5 signal cable) or RJ11 line. Maipu Confidential & Proprietary Information Page 25 of 55... -
Page 25: Ip Module (Vop/Vos) Series
1VOP module may not have this light. If it has, the light will be not on 1VOP Module Connected C able 1VOP module connected cable is RJ45 (4, 5 signal cable) and RJ11 line. Maipu Confidential & Proprietary Information Page 26 of 55... -
Page 26: 2-Port Ip Phone Module (2Vop)
Light on: After pickup, during the call IP phone module indicator Light on: After pickup, during the call 2VOP Module Connected C able 2VOP module connected cable is RJ45 external cable. Maipu Confidential & Proprietary Information Page 27 of 55... -
Page 27: 1-Port Switch Ip Phone Module (1Vos)
1VOS module may not have this lamp Otherwise, the lamp will never be on 1VOS Module Connected C able 1VOS module connected cable is RJ45 (4, 5 signal cable) and RJ11 telephone line. Maipu Confidential & Proprietary Information Page 28 of 55... -
Page 28: 2-Port Switch Ip Phone Module (2Vos)
2-port switch IP phone module (2VOS) 2-port switch IP phone module (2VOS) indicator: IP phone module indicator. Light on: During the phone call IP phone module indicator. Light on: During the phone call Maipu Confidential & Proprietary Information Page 29 of 55... -
Page 29: Ethernet Module (Ete) Series
H.225 H.245 RTCP G.711 G.723 G.729 Ethernet Module (ETE) Series 1-port Ethernet Module (1ETE) 1-port Ethernet module realizes Ethernet connection. 1ETE Module & Indi cator 1ETE module: 1-port Ethernet module (1ETE) Maipu Confidential & Proprietary Information Page 30 of 55... -
Page 30: Isdn S/T Module (St) Series
1-port ISDN S/T (1ST) module provides 64K or 128K high-speed access and backup. 1 S T M o d u l e & I n d i c a t o r 1ST module: 1-port ISDN S/T module (1ST) Maipu Confidential & Proprietary Information Page 31 of 55... -
Page 31: Isdn S/T Module (Sta) Series
MP2800 routers. It also has all the software and hardware functions of 1- port ISDN S/T (1ST) module. 1STA Module & Indi ctor 1STA module: 1-port ISDN S/T module (1STA) Maipu Confidential & Proprietary Information Page 32 of 55... -
Page 32: Asynchronous Serial Module (A) Series
The 8-async module main function is to complete its data flow receiving and sending only in asynchronous mode and the rate reaches 115.2K. 8 A X M o d u l e 8AX interface module: 8-async serial module (8AX) Maipu Confidential & Proprietary Information Page 33 of 55... - Page 33 Maximum BR (bps) 115.2K Supported services Terminal (with terminal number fixed function) PC working station Router Frequency-band or base-band modem PC or router dialup Other serial equipment Supported protocols X.25 HDLC SLIP Maipu Confidential & Proprietary Information Page 34 of 55...
-
Page 34: Installation
Router AC power supply is soft start control switch, which does not cut the main return circuit of AC power supply. During installation, the control switch of main return circuit so as to cut down power supply fast in case of accidents. Maipu Confidential & Proprietary Information Page 35 of 55... -
Page 35: Environment Requirements
15 days for the annual total. Extreme adverse working environment means environment temperature and humidity when the air-conditioning system in the computer room fails. Each time the normal work should be recovered within less than 5h. Maipu Confidential & Proprietary Information Page 36 of 55... -
Page 36: Dust-Free Environment
To prevent the damage caused by the static, do as follows: Ensure proper equipment grounding Maintain dustproof room Keep suitable temperature & humidity Wear anti-static equipment Maipu Confidential & Proprietary Information Page 37 of 55... -
Page 37: Electromagnetic Environment Requirements
Ensure that the protect ground of the chassis is well grounded; Ensure that the grounding point of AC power supply jack is well grounded; Maipu Confidential & Proprietary Information Page 38 of 55... -
Page 38: Check Routers & Accessories
Tools & Equipment Tools Slotted point screwdriver/cross point screwdriver Level, ruler or tapeline Anti-static equipment Connected cables Cables in the package Equipment HUB or Ethernet switch Configuring terminal (can be PC) Maipu Confidential & Proprietary Information Page 39 of 55... -
Page 39: System Installation
Checking Cabinet Maipu devices are designed according to the dimension of 19-inch standard cabinet, so they can be installed and fixed normally on 19-inch standard cabinet. Before installation, reserve enough slot room for installing the device. - Page 40 Usually, it is required that one device is placed on a pallet or a bracket. It is not recommended to overlap multiple devices. Maipu Confidential & Proprietary Information Page 41 of 55...
-
Page 41: Checking Routers & Accessories
Step 2: Place the device on the fixed platform. Align the installation hole of the bracket and the corresponding place of the device. Use the screw to fix the bracket on the two sides of the device. Maipu Confidential & Proprietary Information Page 42 of 55... - Page 42 When installing devices in the cabinet, it is recommended to reserve a space of 1U height between devices to ensure the space for heat dissipation of devices. Install the baffle board configured with the cabinet in the space between devices. Maipu Confidential & Proprietary Information Page 43 of 55...
-
Page 43: Main Control Board Cable Connection
The chassis ground (that is protect ground) must be connected to the ground, so as to make induction electricity and leaked electricity flow to the earth and improve the feature of anti electromagnetic interference. Maipu Confidential & Proprietary Information Page 44 of 55... -
Page 44: Connecting Power Supply
MIM PC power supply jack for reliable grounding. When laying cables for buildings, the ground wires of the power supply system have been installed underground. Users should ensure the reliable grounding and make the corresponding processing. Maipu Confidential & Proprietary Information Page 45 of 55... - Page 45 Step 3: Check whether the power supply indicator of the front panel is If not, repeat step 1 and 2. If the power supply indicator is not on after repeating the above steps, contact the agent. Maipu Confidential & Proprietary Information Page 46 of 55...
-
Page 46: Module Installation
Insert the module to slot. Insert the module circuit board into interface card slot. Push in the module close to back panel. Tighten the screw. According to the contrary order, you can dismantle the modules. Maipu Confidential & Proprietary Information Page 47 of 55... -
Page 47: Module Interface Cable Connection
Sync/async serial supports different signal standards and baud rates in different working modes. Choose cables as per prevailing conditions. The maximum transmission distance and baud rate of signals are related with the cables. Maipu Confidential & Proprietary Information Page 48 of 55... - Page 48 If WAN is dialup line, connect (V.24 cable) to analog Modem serial. During the connection, make sure about the ID on the interface to avoid inserting to other interfaces, which causes the damage of modules and router host. Maipu Confidential & Proprietary Information Page 49 of 55...
- Page 49 Insert RJ11 plug of 1M336 module cable to LINE jack. During the connection, make sure about the ID on the interface to avoid inserting to other interfaces, which causes the damage of modules and router host. Maipu Confidential & Proprietary Information Page 50 of 55...
- Page 50 1VOS/2VOS card back panel. The indicator and Active light should be During the connection, make sure about the ID on the interface to avoid inserting to other interfaces, which causes the damage of modules and router host. Maipu Confidential & Proprietary Information Page 51 of 55...
- Page 51 Connect another side of RJ45 plug to equipment wire. During the connection, make sure about the ID on the interface to avoid inserting to other interfaces, which causes the damage of modules and router host. Maipu Confidential & Proprietary Information Page 52 of 55...
-
Page 52: Cables
---- ---- Twisted-pair 4 ---- ---- RJ45 cross cable (type-5 twisted-pair) connection relation: RJ45 Signal Direction RJ45 Description Length —> Twisted-pair 1 —> <— Twisted-pair 2 <— Twisted-pair 3 Twisted-pair 4 Maipu Confidential & Proprietary Information Page 53 of 55... -
Page 53: Console Port Cable
8-core non-screen cable. One side is RJ45 plug and another is DB9 (hole). 5 4 3 2 1 9 8 7 6 RJ45 jack Standard DB9 interface Console port cable connection relation: RJ45 Signal Direction Length —> —> —> <— <— <— Maipu Confidential & Proprietary Information Page 54 of 55... -
Page 54: Rm2-1E1 & Rm2-1Ce1 Using Rj45-Rj45 Crossing Twisted-Pair
When using RJ45 interface of E1 card, use RJ45-RJ45 cross twisted-pair. Make the cables according to the cable sequence described in the following table. E1 and CE1 using RJ45-RJ45 cross twisted-pair: RJ45 Signal Direction RJ45 <— <— —> —> Maipu Confidential & Proprietary Information Page 55 of 55...
