- Page 1 Install Install Manual Manual SM4200-28FC(52FC) SM4200-28FC(52FC) Install Install Manual Manual V2.0 Maipu Communication Technology Co., Ltd No. 16, Jiuxing Avenue Hi-Tech Park Chengdu, Sichuan Province P. R. China 610041 Tel: (86) 28-85148850, 85148041 Fax: (86) 28-85148948, 85148139 URL: http:// www.maipu.com Mail: overseas@maipu.com...
- Page 2 Maipu makes no representations or warranties with respect to this document contents and specifically disclaims any implied warranties of merchantability or fitness for any specific purpose. Further, Maipu reserves the right to revise this document and to make changes from time to time in its content without being obligated to notify any person of such revisions or changes.
-
Page 3: Maipu Feedback Form
SM4200-28FC (52FC) Install Manual V2.0 Maipu Feedback Form Your opinion helps us improve the quality of our product documentation and offer better services. Please fax your comments and suggestions to (86) 28-85148948, 85148139 or email to overseas@maipu.com. Document Document Document Document Title... -
Page 4: Table Of Contents
SM4200-28FC (52FC) Install Manual V2.0 Contents Contents Contents Contents Product Introduction ....................... 5 5 5 5 Product Product Product Introduction Introduction Introduction ..............................................................Overview ..............................5 ..........................5 Product Introduction Overview ..............................5 Product Features ............................5 ............................7... -
Page 5: Product Product Introduction Introduction
DC power supply Product Introduction Overview The front panel of SM4200-28FC provides 12 Gigabit optical interfaces and 12 Combo interfaces. The front panel of SM4200-52FC provides 44 Gigabit optical interfaces and 4 Combo interfaces. Both SM4200-28FC and SM4200-52FC can realize the 48V DC power input. - Page 6 SM4200-28FC (52FC) Install Manual V2.0 SM4200-52FC provides 44 Gigabit optical interfaces, 4 Gigabit Combo interfaces (Gigabit optical port SFP/Gigabit electric port combo port), and two extended card slots. Secure Secure power power supply supply guarantee guarantee � � � �...
-
Page 7: Physical Features
10％-90％ Table 1-1 Physical features Product Appearance Front Panel The front panel of SM4200-28FC provides 12 Gigabit optical ports, 12 Gigabit Combo ports, eight indicators, and one Console port, as shown in the following figure. Maipu Confidential & Proprietary Information... -
Page 8: Back Panel
Figure 1-3 SM4200-28FC back panel The back panel of SM4200-52FC is the same as that of SM4200-28FC, providing two extended card interfaces, one -48V DC power input interfaces, and one 220V AC power input interface from left to right, as... -
Page 9: Indicators
1-4 of the RJ45 connector. The other is the system indicators. The system status indicators of SM4200-28FC are at the right side of the front panel. The system status indicators of SM4200-52FC are all one group of 2*4 ranging LEDs. The bottom of each LED has the corresponding name. -
Page 10: Front Panel Interface Description
SM4200-28FC (52FC) Install Manual V2.0 indicators are used to indicate the working status of the switch and the port status of the extended card. Table 1-4 SM4200-28FC / SM4200-52FC system status indicator LED Panel Tag Status Meaning On (green) The internal power of the device works normally... -
Page 11: Sm42-2Xfp / Sm42-2Xgef / Sm42-2Gef Extended Module Description
SM4200-28FC (52FC) Install Manual V2.0 SFP-SX-L transceiver: � 1000Base-SX SFP(850nm, MMF, 550m) SFP-LX-L transceiver: � 1000Base-LX SFP interface card module (1310nm, SMF, 10km or MMF, 550m) SFP-LX-20-L transceiver: � 1310nm light wave, 9/125um single-mode fiber: 20km SFP-LX-40 transceiver: � 9/125um single-mode: 40km SFP-LH-70-L transceiver: �... - Page 12 The back panel diagram after the switch is installed with the extended module is as follows: Figure 1-10 Back panel after SM4200-28FC / SM4200-52FC is installed with the extended module The indicator description of the extended module: Table 1-6 Indicator description of 10G...
- Page 13 SM4200-28FC (52FC) Install Manual V2.0 Green light The port is in the 10G connection state The port is in the 10G active connection Link/Activity Flashing green light state No connection or the connection fails Table 1-7 XFP and SFP+ 10G fiber transceiver description...
-
Page 14: Device Device Installation Installation
SM4200-28FC (52FC) Install Manual V2.0 Device Installation Device Installation Device Device Installation Installation Installation Notice To ensure the security of you and others, as well as the normal running of the switch when installing and using the switch, read the following instructions. -
Page 15: Power Supply
SM4200-28FC (52FC) Install Manual V2.0 The switch will get damaged if the air comprises salt, acid and sulfide contents. Such harmful gases speed up metal corrosion and aging of some parts. The site should avoid harmful gases such as SO2, H2S, NO2, NH3 and Cl2. - Page 16 SM4200-28FC (52FC) Install Manual V2.0 The building’s circuit protection system should include a fuse or circuit- breaker of no greater than 240 V, 10 A in the circuit. It is recommended to use a UPS for more reliable power supply.
-
Page 17: Installation Instructions
SM4200-28FC (52FC) Install Manual V2.0 � Every device in the rack generates heat during operation. Provide good ventilation and fans for the enclosed rack. Do not stack devices closely. � When mounting devices in an open rack, prevent the rack frame from obstructing the switch ventilation. -
Page 18: Installation Preparation
SM4200-28FC (52FC) Install Manual V2.0 � No contact between metals and the working power is allowed, and do not drop metals into the switch, to prevent short-circuit and device damages. � Do not touch the power plug and power socket, to prevent electric shock. -
Page 19: Device Installation
SM4200-28FC (52FC) Install Manual V2.0 Antistatic uniform � ␇ Caution Caution Caution Caution The user should prepare the tools by himself. Device Installation Install Switch Install the switch to the standard 19” rack. Figure 2-1 Install the switch to the rack... -
Page 20: Install Sfp Transceiver
SM4200-28FC (52FC) Install Manual V2.0 Figure 2-2 Connect Console cable to the switch Connect console cable as follows: Find the console cable provided in the accessory kit. Attach one connector of the cable to switch console port. Connect the other side of the console cable to a character terminal (PC). -
Page 21: Install Sm42-2Xfp Extended Module
SM4200-28FC (52FC) Install Manual V2.0 Install SM42-2XFP Extended Module The switch provides 10G slot. The steps for installing SM42-2XFP module and the XFP 10G fiber transceiver on the module are as follows: Put on ESD wrist strap (or antistatic gloves);... -
Page 22: Connect Cable/Fiber
SM4200-28FC (52FC) Install Manual V2.0 on ESD wrist strap (or antistatic gloves); Insert the SM42-2GEF module into the inside guide rail of the 10G extended slot; Push SM42-2GEF module along the guide rail until connecting the front panel closely; Insert SFP transceiver into the inside guide rail of the SM42-2GEF module. -
Page 23: Connect Ac Power Cable
The input voltage should be within the required range, or switch can be damaged or cannot work normally. If the power indicator is not blinking even after power on or self-check is abnormal, contact the dealer or Maipu Customer Service Center. Do not open the switch shell without permission. - Page 24 The input voltage should be within the required range, or switch can be damaged or cannot work normally. If the power indicator is not blinking even after power on or self-check is abnormal, contact the dealer or Maipu Customer Service Center. Do not open the switch shell without permission.
