Maipu MP1800 Install Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

MP1800 Router Install Manual
V1.2
Maipu Communication Technology Co., Ltd
No. 16, Jiuxing Avenue
Hi-tech Park
Chengdu, Sichuan Province
People's Republic of China - 610041
Tel: (86) 28-85148850, 85148041
Fax: (86) 28-85148948, 85148139
URL: http://
www.maipu.com
Email:
overseas@maipu.com
Maipu Confidential & Proprietary Information
Page 1 of 55

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP1800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maipu MP1800

Summary of Contents for Maipu MP1800

  • Page 1 MP1800 Router Install Manual V1.2 Maipu Communication Technology Co., Ltd No. 16, Jiuxing Avenue Hi-tech Park Chengdu, Sichuan Province People’s Republic of China - 610041 Tel: (86) 28-85148850, 85148041 Fax: (86) 28-85148948, 85148139 URL: http:// www.maipu.com Email: overseas@maipu.com Maipu Confidential & Proprietary Information...

  • Page 2: Mp1800 Router Install Manual V1

    Maipu makes no representations or warranties with respect to this document contents and specifically disclaims any implied warranties of merchantability or fitness for any specific purpose. Further, Maipu reserves the right to revise this document and to make changes from time to time in its content without being obligated to notify any person of such revisions or changes.

  • Page 3: Maipu Feedback Form

    Maipu Feedback Form Your opinion helps us improve the quality of our product documentation and offer better services. Please fax your comments and suggestions to (86) 28-85148948, 85148139 or email to overseas@maipu.com. Document Title MP1800 Router Install Manual V1.2 Product...

  • Page 4: Table Of Contents

    Production Introduction................6 Product Features ....................6 Hardware Features ....................7 MP1800 Series Multi-service Router Appearance ...............7 Front and Back Panels of MP1800 Series Multi-service Router............7 System Description of MP1800 Series Multi-service Access Router ...........13 Slots of MP1800 Series Multi-service Access Router..............14 Modules....................16 Sync/Async Serial Interface Module (SAE) Series.............
  • Page 5 MP1800 Router Install Manual V1 Install USIM Card ........................31 SM1 Module ......................31 RM2-SM1 Module Appearance....................31 Installation Preparations ................ 32 Security Suggestions .................... 32 Environment Requirements ................... 32 Temperature and Humidity ....................33 Dust-free Environment ......................34 Anti-static ..........................34 Electromagnetic Environment Requirements................35 Anti-lightning ........................35...

  • Page 6: Production Introduction

    MP1800 Router Install Manual V1 Production Introduction MP1800 is one new multi-service router developed by Maipu, integrating the routing technology, switching technology, security technology, 3G, WLAN, traffic control, and network-surf monitoring. It is the MeIN (Multi- service Edge-Intelligent Network) edge network device with high cost- effective and complete functions.

  • Page 7: Hardware Features

    MP1800 Router Install Manual V1 Hardware Features MP1800 Series Multi-service Router Appearance MP1800 multi-service access router Front and Back Panels of MP1800 Series Multi-service Router Front and back panels of RM1800-21-AC router Maipu Confidential & Proprietary Information Page 7 of 55...
  • Page 8 MP1800 Router Install Manual V1 Front and back panels of RM1800-22-AC router Front and back panels of RM1800-23-AC router Front and back panels of RM1800-31-AC router Front and back panels of RM1800-31W-AC router Maipu Confidential & Proprietary Information Page 8 of 55...
  • Page 9 MP1800 Router Install Manual V1 Front and back panels of RM1800-31W-DC48 router Front and back panels of RM1800-35-AC router Front and back panels of RM1800-35W-AC router Front and back panels of RM1800-36W-AC router Maipu Confidential & Proprietary Information Page 9 of 55...
  • Page 10 MP1800 Router Install Manual V1 Front and back panels of RM1800-36-AC router meanings of the indicators on the front and back panels of the above routers: SYS & PWR (system and power) SYS: system status indicator; after the system loads successfully, the indicator flashes slowly;...
  • Page 11 (left): data rate indicator of 100/1000M Ethernet port; on for 1000M and off for 100M; Green light (right): data receiving and sending indicator of Ethernet port The description of the interfaces: The interfaces on the front panel of MP1800 series router Device Type Interface Interface Description...
  • Page 12 Four 1000M Ethernet electric LAN port RJ45 ports USB port One USB interface interface The interfaces on the back panel of the MP1800 series router Interface Interface Type Description Corresponding slot The power switch, ON/OFF ON or OFF AC: 100-240V Max.

  • Page 13: System Description Of Mp1800 Series Multi-Service Access Router

    MP1800 Router Install Manual V1 System Description of MP1800 Series Multi-service Access Router basic configuration and working environment of MP1800 router are as follows: MP1800 router system Item Description Console port One (RJ45), asyn DTE working mode Two 10/100M fast Ethernet ports (RJ45), except for RM1800-21-AC...

  • Page 14: Slots Of Mp1800 Series Multi-Service Access Router

    MP1800 Router Install Manual V1 Rated power 36W±10% (RM1800-31-AC, RM1800-31W-AC, RM1800-31W-DC48); 30W±10% (RM1800-21-AC, RM1800-22-AC, RM1800-23-AC, RM1800- Max. power 35-AC, RM1800-35W-AC); 26W±10% (RM1800-36-AC, RM1800-36W-AC) Slots of MP1800 Series Multi-service Access Router Slots of MP1800 series router Device Type Description RM2-1STA, 8AX, 1/2VoS, 1/2VoP, 4S1O, and SM1 modules are suitable for slot 1, slot 2, and slot 3.
  • Page 15 MP1800 Router Install Manual V1 RM1800-31W-AC, RM1800-31W-DC48, RM1800-35W-AC, and RM1800- 36W-AC support wireless WLAN function. WLAN uses 2.4G frequency band, so the other devices that use 2.4G frequency band will cause interference for WLAN. In serious case, WLAN cannot be used. The 2.4G frequency- band devices include Bluetooth device, microwave oven, digital wireless cordless phone and so on.

  • Page 16: Modules

    MP1800 Router Install Manual V1 Modules MP1800 router is a modular router. It provides three slots. Currently, the available modules include 1SAE, 1CE1, 1E1, 1STA, 8AX, 1VOP, 2VOP, 1VOS, 2VOS, 4S1O, 1ADSL, 2SHDSL, 4SHDSL, 3G-CDMA, 3G-GSM, 3G-TD, and SM1. This chapter describes several common modules.

  • Page 17: Channelized E1 Module (Ce1)

    MP1800 Router Install Manual V1 C a b l e s o f 1 S A E I n t e r f a c e M o d u l e 1SAE interface cable is V35 common DTE cable and V24 straight-through DTE cable.

  • Page 18: Non-Channelized E1 (E1) Series

    MP1800 Router Install Manual V1 The meanings of the indicators: On: Cannot check frame sync signal Off: After sync C a b l e s o f 1 C E 1 I n t e r f a c e M o d u l e 1CE1 matches BNC pin coaxial cable and RJ45-RJ45 straight-through twisted-pair.

  • Page 19: Ip Phone Module (Vop/Vos) Series

    MP1800 Router Install Manual V1 The meanings of the indicators: On: Transparent 2M transmission On: Non-transparent and cannot check frame sync signal Off: After sync C a b l e s o f 1 E 1 I n t e r f a c e M o d u l e 1E1 matches BNC pin coaxial cable and RJ45-RJ45 straight-through twisted-pair.

  • Page 20: Ip Phone Module Of 2-Port Phone (2Vop)

    MP1800 Router Install Manual V1 1-port IP phone module (1VOP) The meanings of the indicators: IP phone module indicator, and the light is on during the call Maybe the 1VOP module does not have the indicator, and if yes, the indicator is not on forever.

  • Page 21: Ip Phone Module Of 1-Port Switch (1Vos)

    MP1800 Router Install Manual V1 The meanings of the ind icators: IP phone module indicator It is on during the call after pickup. IP phone module indicator It is on during the call after pickup. C a b l e s o f 2 V O P I n t e r f a c e M o d u l e The cable of the 2VOP module is RJ45 external cable.

  • Page 22: Ip Phone Module Of 2-Port Switch (2Vos)

    MP1800 Router Install Manual V1 1 V O S I n t e r f a c e M o d u l e A p p e a r a n c e & In d ic ato r s...

  • Page 23: Isdn S/T Module (Sta) Series

    MP1800 Router Install Manual V1 2 V O S I n t e r f a c e M o d u l e A p p e a r a n c e & In d ic ato r s...

  • Page 24: Asyn Serial Module (A) Series

    MP1800 Router Install Manual V1 1 S TA I n t e r f a c e M o d u l e A p p e a r a n c e & In d ic ato r s...

  • Page 25: Adsl Module

    PC or router dialup access; Other serial devices; Supported protocols ·X.25 ·HDLC ·PPP ·SLIP ADSL Module RM2-1ADSL module is used by MP1800 series multi-service access router, connecting to Internet via one RJ11 interface. Maipu Confidential & Proprietary Information Page 25 of 55...

  • Page 26: G.shdsl Series Module

    EN indicator and two status indicators, indicating the status of the card. 4-port G.SHDSL RM2-4SHDSL module is used by MP1800 series multi-service access router, realizing 4-port access Internet via one RJ45 interface. Maipu Confidential & Proprietary Information...

  • Page 27: Interface Attributes Of G.shdsl Interface Module

    MP1800 Router Install Manual V1 The appearance of the G.SHDSL interface module: G.SHDSL panel The physical port on the RM2-2SHDSL module panel is RJ45, connecting 4- port telephone twisted-pair to access Internet. There are five indicators on the module panel, that is, EN indicator and four status indicators, indicating the status of the card.

  • Page 28: 3G Series Module

    MP1800 Router Install Manual V1 RM2-4S1O panel C a b l e s o f 4 S 1 O I n t e r f a c e M o d u l e The cable of the 4S1O module is RJ11 cable.

  • Page 29: Rm2-3G-Cdma

    MP1800 Router Install Manual V1 RM2-3G-CDMA RM2-3G-CDMA module needs to insert the CDMA2000 3G module and USIM card. The appearance of the RM2-3G-CDMA module: RM2-3G-CDMA panel The meanings of the indicators on RM2-3G-CDMA module Off: power-off WWAN Green On: power-on Off: weak signal <= -116dBm...

  • Page 30: Rm2-3G-Td

    MP1800 Router Install Manual V1 data traffic, the more quickly the indicator flashes. When there is no traffic, the flash interval is 4s) Off: weak signal <= -103dBm RSSI On: Strong signal >= -55dBm Green Flash: -55dBm > middle/low signal > -103dBm...

  • Page 31: Install Usim Card

    MP1800 Router Install Manual V1 Install USIM Card USIM card is used to store the accounting information. The USIM card is purchased by the user. The metal face of the USIM card is adown. Refer to the appearance diagram of the cassette, Plug and Play.

  • Page 32: Installation Preparations

    Environment Requirements MP1800 series routers must be used indoor. To guarantee stable use of routers and prolong the life, the application scenario must meet the following requirements.

  • Page 33: Temperature And Humidity

    MP1800 Router Install Manual V1 Temperature and Humidity To ensure the service quality and life of MP1800 series routers, it is recommended to maintain a certain temperature and humidity in the computer lab. If the humidity in the computer lab is high for long time, it causes the poor insulation and even electricity leak of insulation materials easily.

  • Page 34: Dust-Free Environment

    0.006 0.05 0.01 Anti-static MP1800 router takes lots of measures in anti-static, but when the static exceeds a certain volume, the circuits even the whole monitor are damaged. For router communication, static electricity originates from external electric field of high-pressure like electricity cables and thunders, and internal system such as floor material and chassis structure.

  • Page 35: Electromagnetic Environment Requirements

    Take electromagnetic shielding methods when necessary. Anti-lightning MP1800 router takes lots of measures in anti-lightning, but when the lightning exceeds a certain volume, the router may be damaged. To prevent the damages caused by lightning, do as follows: Ensure that the protect ground of the chassis is well grounded;...

  • Page 36: Check Routers & Accessories

    MP1800 Router Install Manual V1 Check Routers & Accessories After ensuring the installation environment requirements are met, you can open the package. However, before installation, check whether the router and the accessories are complete according to the purchase order. Tools & Equipment...

  • Page 37: System Installation

    Cabinet Installation Check Cabinet After MP1800 router is configured with the private brackets, it can be installed and fixed normally on 19-inch standard cabinet. Before installing MP7500, reserve enough slot room. Maipu Confidential & Proprietary Information...
  • Page 38 MP1800 Router Install Manual V1 Center distance of the horizontal installation hole and net horizontal installation space Use the level or tapeline to measure the center distance of the horizontal installation hole and net horizontal direction installation space of the cabinet.
  • Page 39 MP1800 Router Install Manual V1 Check whether the floating nut for fixing the device is installed in the square hole of the cabinet column. If not, insert the floating nut to the square hole according to the position of the pallet or tray.
  • Page 40 MP1800 Router Install Manual V1 In s ta l l M P1 80 0 on C abi net Install MP1800 multi-service access router in the cabinet: Step 1: Wear the gloves and anti-static wrists, and make the anti-static wrists well grounded;...

  • Page 41: Install Device On Desk

    1U height between the devices. Install the configured baffle of the cabinet between the devices. Install Device on Desk MP1800 has the features of small volume and no noise. The user can place the device on the office desk or other platform. Caution When MP1800 is installed on the office desk or platform, there should be 50cm space reserved around the device for ventilation and cooling.

  • Page 42: Connect Host Cables

    Step 2: Embed the plastic expansion screw into the wall and there should be 3-4mm space between the screw end and the wall; Step 3: Make the hang foot opening of MP1800 host aim at the expansion screw, push MP1800 slowly, and fix the device on the wall.

  • Page 43: Connect Protection Ground Wire

    4Ω. If the router is installed on the 19-inch standard cabinet, the cabinet should also be grounded. Connect Power Supply MP1800 router adopts stable power supply switch system and has a low requirement for input AC. It supports 110V and 220V 50Hz AC. Different areas have different power supply systems.
  • Page 44 MP1800 Router Install Manual V1 -40V－-57V, 2A DC power module Power ports of AC device Power ports of DC device When connecting power supply, use the below suggested power supply jack or MIM PC power supply jack for reliable grounding. When laying cables for buildings, the ground wires of the power supply system have been installed underground.

  • Page 45: Module Installation

    Live wire Connect the power supply as follows: Step 1: Put the power supply switch of MP1800 to OFF. For AC router, connect one side of AC power supply cable to the AC power input end of the back panel of the router and another side to power supply jack; for DC router, connect the power cable to the post according to the description of panel silk screen on the interface.
  • Page 46 Usually, the router serves as DTE device. Whether the type of the device connected to the router is DTE or DCE refers to the MP1800 manuals. Typical DTE and DCE devices...

  • Page 47: Connect 1Ce1/1E1 Module Interface Cable

    MP1800 Router Install Manual V1 2400 1250 4800 9600 19200 38400 56000 64000 2048000 Note When adopting EIA/TIA-232 cable, BR rate should not be over 64Kbps in syn mode. C o n n e c t 1 S A E M o d u l e I n t e r f a c e C a b l e...

  • Page 48: Connect 1Vop/2Vop Module Interface Cable

    MP1800 Router Install Manual V1 TX cable should be connected with the RX cable of the peer device. The RX cable should be connected with TX cable of the peer device. Step 3: After power on, check LOS status of 1CE1/E1 module. If indicator is on, it indicates that the circuit fails and signal loses sync, so check the line.

  • Page 49: Connect 1St Module Interface Cable

    MP1800 Router Install Manual V1 Step 1: Connect the phone cable to the RJ11/RJ45 interface of 1VOS/2VOS and the other side to the small switch or external distribution box. Step 2: During the call, pay attention to the indicator on the back panel of the 1VOS/2VOS card.

  • Page 50: Connect G.shdsl Module Interface Cable

    MP1800 Router Install Manual V1 Connect G.SHDSL Module Interface Cable Step 1: Connect the RJ45 plug of the G.SHDSL module interface cable to the RJ45 jack. Step 2: Connect the other side of the RJ45 plug to the corresponding device.

  • Page 51: Cables

    Cables Ethernet Interface Cable Ethernet interface cable of MP1800 router adopts 8-core non-screen twisted pair. In 10BASE-T and 100BASE-TX mode, silver plate 1 and 2 are the sending ends; silver plate 3 and 6 are the sending ends. In 1000BASE- T mode, silver plate 1, 2, 3, 4, 5, 6, 7, and 8 are all used for receiving and sending signals.

  • Page 52: Ethernet Optical Interface Cable

    The Ethernet optical interface cable of MP1800 is the single-mode or multi- mode fiber pf the LC interface. Console Port Cable MP1800 console port cable is connected with PC 9-core serial jack, and it is 8-core non-screen cable. One side is RJ45 plug and another is DB9 (hole).

  • Page 53: 4S1O Interface Distribution Box

    MP1800 Router Install Manual V1 4S1O Interface Distribution Box Usage: Used to separate the FXO/FXS mixed signals of the 4S10 card. Description: Three port distribution boxes, including one input RJ11 port LINE and two output RJ11 port FXS and FXO. The input end needs to connect the 4-core telephone line and the output end needs to connect the 2-core telephone line.

  • Page 54: G.shdsl Interface Cable

    MP1800 Router Install Manual V1 RJ-11 RJ-11 Color Length Black 0.5m Green Yellow Note: The pins of the RJ11 crystal head are as shown in the following figure. The side facing the contact chip of the crystal head are pin 1, pin 2…...
  • Page 55 MP1800 Router Install Manual V1 The pin order of RJ-45 crystal head Maipu Confidential & Proprietary Information Page 55 of 55...
