Menu Settings
GL2 Line &
Settings Pen
Manag-
er
Proces-
singOp-
tion
424
GL2 Set Print
Inter- EOP Timer
face
Setup
TCP/IP
Setting Item
Smoothing
ThickenFineLines
AdjustFaintLines
Ln wdth correct
Warning
On-the-Fly
Detect img size
IPv4 IPv4 Mode
Proto- DHCP
col
Description, Instructions
•
If you choose Software
Operation is determined by the application. If nothing
is specified by the application, the result is as shown in
the figure.
Note: By default, this is a 72-sided figure
•
If you choose Smooth
Select On to print fine lines more distinctly.
If fine lines are printed in colors that do not match the col-
ors of other shapes, selecting Off may help produce the
expected results. However, lines in some colors may ap-
pear broken.
Corrects by using a correction value that specifies the pen
width.
You can configure Black/gray and Color for each group.
The specified range is -20 to +20.
Select On to have any GL2-related warnings displayed.
Selecting On will start printing jobs sooner if you are print-
ing only HP RTL print jobs and printing would not start un-
til later. However, images may be incomplete in some ca-
ses, so be sure to check the printing results.
Sets the method of deciding the region to output in order
to print efficiently while avoiding missing images.
If Off is selected and the data contains image range infor-
mation, the image range information is followed.
If Off is selected and the data does not contain image
range information, a size with the maximum roll paper
width of the printer for the width and 1.5 times the maxi-
mum roll paper width for the length is used.
If Command priority is selected and the data contains
image range information, the image range information is
followed.
If Command priority is selected and the data does not
contain image range information, the detected minimum
image area is used.
If Detected size is selected, the detected minimum image
area is used.
Print GL2 settings information.
Specify the timeout period before cancellation of print jobs
that cannot be received by the printer.
Choose whether the printer IP address is configured auto-
matically or a static IP address is entered manually.
Specify the protocol used to configure the IP address au-
tomatically.
