Menu Settings
Adjust Feed
Printer Priority
Mainte- Head Cleaning
nance
Nozzle Check
Replace P.head
Repl. maint cart
Head Info
GL2 Quality
Settings Manag-
er
Paper
Manag-
er
422
Setting Item
Adjust Change B:Standard/Draft
Length Settings
Color Monochrome
Mode
Color (CAD) 1
Color (CAD) 2
Color (CAD) 3
Color (CAD) 4
Color (CAD) 5
Print Quality
Input Resolution
Print (Economy)
Paper Source
Margin
Oversize
Conserve Paper
Description, Instructions
For paper that tends to stretch, increase the feed amount
by choosing a higher adjustment value. For paper that
tends to shrink, decrease the feed amount by choosing a
lower adjustment value. (See "Adjusting Line
Length.")
P.533
➔
Clean the Printhead. (See "Cleaning the Print-
head.")
P.547
➔
Choose Head Cleaning A if printing is faint, oddly col-
ored, or contains foreign substances.
Choose Head Cleaning B if no ink is printed at all, or if
printing is not improved by Head Cleaning A.
Print a test pattern to check the nozzles.
Execute when replacing the Printhead. Follow the instruc-
tions displayed to complete the required procedure. (See
"Replacing the Printhead.")
➔
Not displayed during a warning message that the remain-
ing Maintenance Cartridge capacity is low.
Execute when replacing the Maintenance Cartridge. Fol-
low the instructions displayed to complete the required
procedure. (See "Replacing the Maintenance Car-
tridge.")
P.554
➔
Indicates information about the printhead.
Print in monochrome.
Print in standard colors.
Print with approximate colors emulating Canon iPF750,
iPF755, iPF650, iPF655, iPF760, iPF765.( *2 )
Print with approximate colors emulating Canon iPF500,
iPF600, iPF700, iPF510, iPF610, iPF710, iPF605, iPF720,
iPF810, iPF820, iPF815, iPF825.( *2 )
Print emulating the HP Designjet 500/800, in colors re-
sembling colors produced by these printers.( *2 )
Print emulating the HP Designjet T1100, in colors resem-
bling colors produced by this printer.( *2 )
Choose the print quality.
Choose the printer input resolution, 600dpi or 300dpi.
When On is selected, print using less ink.
However, the quality is lower than regular printing.
Select On to conserve ink such as the layout confirmation.
Note that although Print (Economy) is only available
when Fast is selected in Print Quality, it might not be
available depending on the paper type.
Choose the source of paper for HP-GL/2 printing.
Specify the margin around paper. The margin for the trail-
ing edge of sheets is 23 mm (0.9 in).
However, if you have specified the leading margin in Pa-
per Details, the larger of the setting values has priority.
Set the position of the margin relative to the image range.
Choose Off to set the margin inside the image range.
The image may be missing depending on the layout.
Choose On to set the margin outside the image range.
Although the image will not be missing, you should print
on paper larger than the size of the image range plus the
margins.
Conserves paper when printing.
iPF685
P.548
User's Guide
