iPF685
Test
Print Job Log
Print
Menu Map
Color Palette
Adjust Head Auto(Standard)
Printer Posi.
Adj.
Auto(Advanced)
Manual
Head Inc. Adj.
Feed Adj. Pri-
Priority ority
Adj.
Quality
Adjust
Length
User's Guide
Setting Item
Automatic
Print Quality
Print Length
Auto(GenuinePpr)
Auto(OtherPaper)
Manual
Adjust- A:High
ment-
B:Standard/Draft
Print
Change A:High
Settings
B:Standard/Draft
Description, Instructions
Print a record of print jobs, including the paper type and
size, amount of ink consumed, and so on. Ink consump-
tion indicates a rough estimate of the amount of ink con-
sumed per print job.( *1 )
Print the menu structure.
Print the GL2 color palette.
The printer prints and reads a test pattern for automatic
adjustment of Printhead alignment relative to the printing
direction. (See "Automatic Adjustment to Straighten
Lines and Colors.")
P.522
➔
The printer prints and reads a test pattern for automatic
adjustment of Printhead alignment relative to the printing
direction and spacing between nozzles and colors. (See
"Automatic Adjustment to Straighten Lines and Col-
ors.")
P.522
➔
Print a test pattern for adjustment of Printhead alignment
relative to the printing direction. Enter the adjustment val-
ue manually based on the resulting pattern. (See "Manual
Adjustment to Straighten Lines and Colors.")
Print a test pattern for adjustment of the Printhead orienta-
tion. (See "Adjusting Line Misalignment.")
Specify exact paper feeding, if desired. Normally, select
Automatic. Choose Print Quality for attractive printing.
Choosing Print Quality also makes banding less noticea-
ble. Choose Print Length if you prefer to feed the paper
an exact amount.
Specify this mode with paper identified in the Paper Ref-
erence Guide. (See "Displaying the Paper Reference
Guide.")
P.331
➔
The printer prints and reads a test pattern for automatic
adjustment of the feed amount. (See "Automatic Banding
Adjustment.")
P.530
➔
Specify this mode with paper not in the Paper Reference
Guide. (See "Displaying the Paper Reference
Guide.")
P.331
➔
The printer prints and reads a test pattern for automatic
adjustment of the feed amount. Note that this function
takes more time and consumes more ink than Auto(Gen-
uinePpr). (See "Automatic Banding Adjust-
ment.")
P.530
➔
Use this mode with highly transparent media or other pa-
per for which Auto(GenuinePpr) or Auto(OtherPaper)
cannot be used.
Print a test pattern for adjustment of the feed amount
based on the type of paper. (See "Manual Banding Ad-
justment.")
P.531
➔
Print a test pattern for particular types of paper to com-
pensate for paper stretching or shrinkage, after which you
enter the amount of adjustment. (See "Adjusting Line
Length.")
P.533
➔
Displayed when you have selected Feed Priority > Adj.
Priority > Print Length.
Adjustment relative to the amount of stretching or shrink-
age of the current paper.
Enter either the adjustment results from AdjustmentPrint
or the discrepancy that you measured (as a percentage).
Menu Settings
P.523
➔
P.525
➔
