SET-UP INSTRUCTION

FIRST OPERATION
1) Please remove carefully all the protecting foam and
check the items listed are all supplied.
2) Place the Mediterraneo deck on a levelled surface,
the best is a wall shelf immune to footfall, then level
the turntable.
3) Plug the tone arm cable pre installed to the amplifi-
er phono input.
4) Install the counterweight into the rear arm wand of
the arm adjusting the correct cartridge tracking
weight with the help of a precision scale (not
supplied).
5) Install the turntable belt surrounding the hourglass
motor pulley and the platter outer perimeter.
6) Plug the Power Adapter cable to the 12V rounded
plug Turntable Speed Control ; then plug the AC
adapter to the AC plug once selected the right inter
national plug supplied. Connect the mini-XLR plug of
the cable coming from the motor of the turntable to the
TSC.
POSITIONING THE VALORE 425
Your VALORE turntable has been designed for home
Hi-Fi systems. It must be protected from direct
sunshine rays and humidity. Do not put it close to
strong heating sources, electrical and electronic
motors, mobile phones etc.
The levelling and positioning on a solid shelf, as
explained in the previous chapter, is fundamental to
ensure the best audio performances.
TURNTABLE SPEED CONTROL ADJUSTMENT:
The turntable is fully controlled by an electronic power
supply operating the Turntable 33⅓ rpm & 45 rpm
while having a Pitch control also.
• Inner Button Start and Stop the 33⅓r pm speed.
OWNER'S MANUAL OWNER'S MANUAL
Once the 33⅓rpm is playing its red LED light turn on.
•Outer Button Start and Stop the 45rpm speed. Once
the 45rpm is playing its red LED light turn on.
The turntable also features a fine speed adjust "Pitch
Control" allows a very fine adjust of the speed of the
turntable.
PITCH CONTROL MODE
To enter the PITCH CONTROL MODE is necessary to
press and hold for 3/4 seconds both 33⅓and 45
buttons together while the turntable playing 33⅓or
45rpm. The related red LED light shut down and the
unit is ready to adjust the fine speed with the help of
the stroboscope.
• PITCH – pressing in sequence the 33⅓rpm button
its LED light flashes fine speed decrease.
• PITCH + pressing in sequence the 45rpm button its
LED light flashes fine speed increase.
To get out the PITCH CONTROL MODE press and
hold for 3/4 seconds both 33⅓and 45 buttons togeth-
er, the LED related to the speed adjusted will show
back.
REFERENCE IMAGE PAG.12
The TURNTABLE SPEED CONTROL unit records
permanently in the turntable memory the speed
adjusted singularly for both 33⅓and 45rpm even if
the unit is unplugged from the AC wall.
