SET-UP INSTRUCTION

FIRST OPERATION
1 Please remove carefully all the protecting foam and
check the items listed are all supplied.
2 Place the turntable on a levelled surface, such as a wall
shelf immune to footfall, then level the turntable.
3 Plug the pre-installed cable into the amplifier phono
input.
4 Install the counterweight into the rear arm wand of the
arm selecting the correct cartridge tracking weight with
the help of a precision scale (not supplied).
5 Install the turntable belt surrounding the hourglass
motor pulley and the platter outer perimeter.
6 Plug the Power Adapter cable to the 12V Turntable.
Speed Control, then plug the AC adapter into the wall
socket.
Connect the mini-XLR plug of the cable coming from the
motor of the turntable to the TSC.
POSITIONING THE VALORE 425 PLUS
Your Valore 425 Plus turntable has been designed for
Hi-Fi systems.
It must be protected from direct sun and humidity.
Do not place it near heating sources, electrical and
electronic motors, mobile phones etc.
The levelling and positioning on a solid shelf, as explained
in the previous chapter, is fundamental to ensure the best
audio performances.
OPERATING THE 33⅓rpm & 45rpm CONTROL
The turntable is fully controlled by an electronic power
supply.
7
TURNTABLE SPEED CONTROL ADJUSTMENTS
• Inner button starts and stops the 33⅓rpm speed.
Once the 33⅓rpm is playing its red LED light turns on.
• Outer button starts and stops the 45rpm speed.
Once the 45rpm is playing its red LED light will be on.
The turntable also features a fine speed adjustment
"Pitch Control" function to allow a very fine and precise
speed calibration.
PITCH CONTROL MODE
To enter the PITCH CONTROL MODE press and hold for 4
seconds both 33⅓rpm and 45rpm buttons while the
turntable is spinning.
When the red LED light shuts down, the unit is ready for
the fine speed adjustment.
• PITCH –
press repeatedly the 33⅓rpm button until the correct
speed is reached.
The LED light flashes every time the button is pressed.
• PITCH +
press repeatedly the 45rpm button until the correct speed
is reached.
The LED light flashes every time the button is pressed.
See pag.14 for images.
To switch off of the PITCH CONTROL MODE press and hold
for 4 seconds both the 33⅓rpm and the 45rpm buttons
until the LED light is on and steady again.
