Gold Note VALORE Plus 425 Owner's Manual page 13

POWER ADAPTER & SPEED CONTROL
DC out
(motor)
TSC REAR PANEL
TURNTABLE SPEED CONTROL ADJUST:
• 33rpm BUTTON Start and Stop the 33⅓r pm speed. Once the 33⅓rpm is playing its red LED light turn on.
• 45rpm BUTTON Start and Stop the 45rpm speed. Once the 45rpm is playing its red LED light turn on.
The Valore 425 also features a fine speed adjust "Pitch Control" allows a very fine adjust of the speed of
the turntable.
PITCH CONTROL MODE
To enter the PITCH CONTROL MODE is necessary to press and hold for 3/4 seconds both 33⅓ and 45
buttons together while the turntable playing 33⅓ or 45rpm. The related red LED light shut down and the
unit is ready to adjust the fine speed with the help of the stroboscope.
• PITCH – pressing in sequence the 33⅓rpm button its LED light flashes fine speed decrease.
• PITCH + pressing in sequence the 45rpm button its LED light flashes fine speed increase.
To get out the PITCH CONTROL MODE press and hold for 3/4 seconds both 33⅓and 45 buttons together,
the LED related to the speed adjusted will show back.
OWNER'S MANUAL
- Connecting the Power Supply Adapter Use exclsuively the
original GOLD NOTE AC adapter to power the turntable to ensure
the correct performance.
PLEASE NOTE WELL:
rounded connector indicated here.
DC in
insert the mini XLR from
the motor of the
Valore 425 here
Before plugging the AC adapter plug the
33RPM BUTTON
45RPM BUTTON
