ONE100D/M
Installation Guide
4
Interface description
This chapter gives an overview of the different connectors on the back of the ONE100D/M. The following
gives an overview of this chapter:
•
4.1 - The different connectors on the back panel of the ONE100D/M on page 37
•
4.2 - ISDN interface specifications on page 39
•
4.3 - SHDSL line specifications on page 42
•
4.4 - LAN interface specifications on page 43
•
4.5 - WLAN interface specifications on page 44
•
4.6 - 4 port Ethernet switch specifications on page 45
•
4.7 - Console port specifications on page 46
•
4.8 - FXS analog interface specifications on page 47
•
4.9 - FXO analog interface specifications on page 48
Chapter 4
36
Interface description
