23 ONE100D/M
Installation Guide
3.4.2

LED states

The state of the LEDs indicates the following:
LED name
Status
Uplink
IP
WLAN
Aux
Com
Colour Description
Bicolour • OFF: No input power.
• ON - green: Switched on and operational.
• ON - red: Switched on and not operational.
• Blinking green: (Re)boot in progress.
Bicolour • OFF: None of the uplink interfaces (SHDSL, mobile, ISDN data
backup) is configured.
• ON - green: The SHDSL uplink is synchronised.
• ON - red: None of the uplinks is synchronised (although at least
one configured).
• Blinking green: None of the uplinks is synchronised but at least
one uplink synchronisation is in progress.
• Flashing green: The SHDSL uplink is not synchronised, but a
backup interface (ISDN or Mobile) is up.
Bicolour • OFF: No IP routing has been configured.
• ON - green: All IP interfaces on the SHDSL link are up
• ON - red: All IP interfaces are down
• Blinking green: At least one IP interface is up and at least one is
not up on the active uplink.
• Flashing green: All IP interfaces on the backup link (ISDN or
Mobile) are up.
Green • OFF: Not in use.
• ON - green: The WLAN interface is up.
• Blinking green: Traffic in progress.
Bicolour • OFF: Not configured for voice service.
• ON - green: Configured and operational voice service.
• ON - red: Malfunction in the voice service.
• Blinking green: Voice service is configured, verification of voice
function in progress.
Green • OFF: There is no voice communication on any of the voice ports.
• ON - green: There is voice communication on one of the voice
ports.
Chapter 3
Router description
