ONE100D/M
Installation Guide
3.5

Rear view of the ONE100D/M

This section describes the various types of ONE100D/M rear panels, so that the user can identify the
interface type and port numbering.
The following gives an overview of the different models of the ONE100D/M:
• One100D/M-2B-W on page 25
• One100D/M-2B-2B-W on page 26
• One100D/M-4B-W on page 27
• One100D/M-4B-4B-W on page 28
• One100D/M-2V-W on page 29
• One100D/M-2B-2V-W on page 30
• One100 D/M-4B-2V-W on page 31
• One100D/M-4V-W on page 32
• One100D/M-8V-O-W on page 33
For a description of the meaning of the different model names, refer to
overview on page 19, and the following figures.
Note that in this chapter, the connectors that are present on the ONE100D/M by default, are not men-
tioned in the name of the device, only the optional extra connectors are mentioned in the name.
For a detailed description of the function of the different connectors, refer to
tors on the back panel of the ONE100D/M on page
3.2 - ONE100D/M Router family
37.
Chapter 3
Router description
4.1 - The different connec-
24
