SECTION 1
• Frequency coverage
• Type of emission
• Number of programable channels
• Antenna impedance
• Operating temperature range
• Power supply requirement
• Current drain
(approx.)
• Dimensions (with BP-232N, approx.)
• Weight (with BP-232, approx.)
• Transmit output power
• Modulation
• Max. frequency deviation
• Frequency error
• Spurious emission
• Adjacent channel power
• Audio harmonic distortion
• FM hum and noise
(without CCITT filter)
• Limiting charact of modulation
• Microphone impedance
• Receive system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity (at threshold)
• Adjacent channel
selectivity
• Spurious response
• Intermodulation
• Hum and Noise
(without CCITT filter)
• Residual modulation
(with CCITT filter)
• Audio output power
• Audio output impedance
*; Optional digital unit is necessary.
Specifications are measured in accordance with EIA-152-C/204D, TIA-603 (for [USA], [GEN], [EXP]) or EN 300 086 (for [EUR], [FRG]).
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

Wide 16K0F3E (25.0 kHz/30.0 kHz)
Middle
11K0F3E, 11K0F7E/D* (15.0 kHz)
Narrow 8K50F3E, 8K10F1E/D* (12.5 kHz)
4K00F1E/D* (6.25 kHz)
Specified Icom's battery packs only (Operatable voltage; 7.2 V DC negative ground)
Stand-by
RX
Max.audio
at 5 W
TX
at 1 W
3
2 / (W) × 5
32
Wide
Middle
Narrow
Wide
Middle
Narrow
Wide More than 40 dB (46 dB typ.)
Narrow More than 34 dB (40 dB typ.)
0.25 μV typ. at 12 dB SINAD
Wide
Middle
Narrow
More than 70 dB (74 dB typ.)
Wide More than 40 dB (46 dB typ.)
Narrow More than 34 dB (40 dB typ.)
Wide
Middle
Narrow
[USA], [GEN], [EXP]
136–174 MHz
–
512 channels (128 zones)
50 Ω (nominal)
−22˚F to +140˚F
150 mA (with UT-119H/UT-126H)
11 17
/ (H) × 1 / (D) in
32 32
12 oz
5 W (High), 2 W (Low2), 1 W (Low1)
Variable reactance frequency modulation
–
±1.0 ppm
75 dB typ.
More than 70 dB (80 dB typ.)
–
More than 60 dB (70 dB typ.)
3% typ. (with 1 kHz AF 40% deviation)
60–100% of max. deviation
Double conversion superheterodyne
1st IF; 46.35 MHz, 2nd IF; 450 kHz
0.25 μV typ.
More than 70 dB (75 dB typ.)
−
More than 65 dB (68 dB typ.)
More than 70 dB
−
−
−
0.5 W typ. at 5% distortion with an 8 Ω load
1 - 1
[EUR], [FRG]
16K0F3E (25.0 kHz) [EUR-01]
14K0F3E (20.0 kHz) [EUR-01], [FRG-01]
8K50F3E (12.5 kHz) [EUR-01]
4K00F1E/D* (6.25 kHz) [EUR-01]
–25˚C to +55˚C
100 mA
600 mA
1.5 A
0.7 A
53.0 (W) × 136.0 (H) × 38.5 (D) mm
340 g
±5.0 kHz
±4.0 kHz
±2.5 kHz
±1.5 kHz
0.25 μW (≤1 GHz), 1.00 μW (>1 GHz)
More than 70 dB (80 dB typ.)
–
–
2.2 kΩ
− 4 dBμV (EMF) typ. at 20 dB SINAD
More than 70 dB (75 dB typ.)
More than 65 dB (67 dB typ.)
−
−
More than 45 dB (55 dB typ.)
More than 43 dB (53 dB typ.)
More than 40 dB (50 dB typ.)
8 Ω
