Icom IC-F3061T Servise Manual page 38

• For F3160 series
• FRONT UNIT (TOP VIEW)
[10-key] only
to VR unit J701
• MAIN UNIT (TOP VIEW)
2 20
J4
1 19
1
J2
X3
40 D_IF D_IF 1
GND GND
+5V NC
VCC NC
NC NC
NC DMO
NC NC
DMI
NC
NC NC
DISC VREF
NC NC
DAFO NC
NC NC
CCS OPT1
CIRQ OPT2
NC OPT3
CSO GND
CSI NC
J2
CCK GND
21 GND GND 20
to optional unit
J1
40 NC NC 1
GND GND
+5V PTTI
VCC PTTO
NC MCOT
MMUT NC
AFONO MCIN
BEPO NC
RMUT NC
DISC NC
AFOUT NC
NC BUSY
REM SIGO
CCS OPT1
CIRQ OPT2 J1
NC OPT3
CSO GND
CSI OPV3
CCK OPV2
21 GND OPV1 20
X
to optional unit
9 - 3
RXRF
HV
GND ISENS
from RF
T2 GND from RF
unit J602
unit J601
T5V
TXRF
TMUT GND
+5V
T2-
-R5V
7
-S5V
RLVA
NWC2-
EPTT-
-TEMP
CP4
AFOUT
CP2 MIC
CP3
-TENC
-CSK
-CCK
-NWC1
-POSW
+5V
PTT
-PLST
-CDEC
-RXC
-CPU5V
RES-
SCRM
RSSI
B6677B
VHF
CP22
2 X 4
• RF UNIT (TOP VIEW)
C649
J601
R622
5 GND
TXRF
C644 C645
GND
R625 Q605
ISENS
C654
1 HV
to MAIN unit
J601
C637
• JACK UNIT (TOP VIEW)
MP801
B6421D
• VR UNIT (TOP VIEW)
EMER
J3
20
1 to FRONT unit J501
B6420C
R701
• BC-160 (TOP VIEW)
from battery
C630
IC601
F601
D607
C659
J602
R611
5 TMUT
T5V
C626
T2
R623
GND
J602 1 RXRF
R624
to MAIN unit
C613
B6419D
R605
R604 CHASSIS
R601
J1
C619
D604
ANT
MP801
1 9
MULTI
CONNECTOR
2 8
DS701
Q701
(No patterns )
