Icom IC-F3061T Servise Manual page 34

[RF UNIT]
REF. PARTS
NO. NO.
J601 6910017940 IMSA-9230B-1-05Z118-PT1
J602 6910017940 IMSA-9230B-1-05Z118-PT1
F601* 5210000970 ERBSE3R00U
MP601* 8510017600 OG-363050
[VR UNIT]
REF. PARTS
NO. NO.
J701* 6510024930 20RF-JMCS-G-1B-TF (N)
S701 2250000490 TP70TF5163 15.9F-2775
S702* 2230001060 EVQ-PUL 02K
[ACCESSORIES]
REF. PARTS
NO. NO.
†
EP1 – FA-SC55V-2
†
EP2 – BP-232N
†
MP1 – MB-94
MP2 8210021471 2803 SIDE PANEL-1
MP3 8810010430 SCREW TRUSS M3X5 SUS SSBC
EP1
EP2
*: Refer to "BOARD LAYOUTS" for the location.
† : Optional product.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
MP1
MP2
MP3
