Icom IC-F3061T Servise Manual page 18

6-3 TRANSMIT ADJUSTMENT (continued)
Select an adjustment item using [↑] / [↓] keys, then set to the specifi ed value using [←] / [→] keys on the connected PC's keyboard.
ADJUSTMENT
1 • Channel
CTCSS/DTCS
• No audio applied to the JIG cable.
DEVIATION
• Set the FM deviation meter to same condi-
[CTCSS/DTCS]
tion as "MODULATION BALANCE."
• Transmitting
1 • Channel
2/5 TONE
• Set the FM deviation meter to same condi-
DTMF***
2
tion as "MODULATION BALANCE."
[S.Tone]
• Transmitting
***; [F3160] series only.
ADJUSTMENT CONDITION
: CH 19
: CH 7
MEASUREMENT
UNIT OPERATION
Top Connect an FM deviation meter to
panel the antenna connector through
an attenuator.
Top Connect an FM deviation meter to
panel the antenna connector through
an attenuator.
6 - 6
VALUE
±0.68 to ±0.72 kHz
(Other than
[FRG-01])
±0.53 to ±0.57 kHz
([FRG-01])
±1.50 kHz
