RM-356
Service Tools and Service Concepts

Rework jigs and stencils

The table below gives a short overview of service devices that can be used for testing, error analysis, and
repair of product RM-356. For the correct use of the service devices, and the best effort of workbench setup,
please refer to various concepts.
Issue 1
RJ-157
RJ-157 is a rework jig used when servicing the Z7540 duplexer. It is
used together with the ST-55 stencil.
RJ-160
RJ-160 is a rework jig used when servicing the WCDMA duplexer
(Z7541). It is used together with the ST-55 stencil.
RJ-166
RJ-166 is a jig used when servicing the accelerometer (N6501).
It is used together with the ST-53 stencil.
COMPANY CONFIDENTIAL
Copyright © 2008 Nokia. All rights reserved.
Rework jig
Rework jig
Rework jig
Page 2 –7
