Summary of Contents for Hyundai HY2524
-
Page 2: Table Of Contents
CONTENTS TITLE PAGE No 1. SAFETY 2. PARTS 3. APPLICATION 4. INSTALLATION INSTRUCTIONS 5. ADDITIONAL SAFETY 6. INSTALLATION & COMISSIONING 10/11 7. TECHNICAL DATA 8. CLEANING & MAINTENANCE 12/13 9. DISPOSAL & RECYCLING 10. TROUBLESHOOTING 11. GENPOWER CONTACT DETAILS 12. DECLARATIONS of CONFORMITY Page 2 Rev 2... -
Page 3: Safety
1. SAFETY. 1.1. The operator of the machine; 1.1.1. Is responsible for and has a duty of care in making sure that the compressor is operated safely and in accordance with the instructions in this user manual. 1.1.2. Should never leave it in a condition which would allow an untrained or unauthorised person/s to operate this compressor. - Page 4 1.3. Electrical Safety. 1.3.1. Electricity can kill - never work on LIVE/ENERGISED equipment. 1.3.2. Identify electrical isolation method and always isolate all electrical supplies, prior to carrying out any maintenance work. 1.3.3. Prior to use and with all electrical supplies isolated check all electrical cables, plugs and connections for the following.
-
Page 5: Parts
2. PARTS. Picture 1. Inlet air filter. Compressor. Oil level indicator. Air tank. Foot. Handle. ON- OFF switch Pressure gauge Picture 2. Pressure relief valve Quick relase outlet. Pressure regulator. Tank drain valve Picture 3. Page 5 Rev 2... - Page 6 2. PARTS Continued. Wheels Wheel bolts Oil filler cap Rubber foot Nut/Bolt for foot Air filter Accessory kit Page 6 Rev 2...
-
Page 7: Application
3. APPLICATION. This compressor is used to produce compressed air for pneumatic tools. 4. INSTALLATION INSTRUCTIONS. 4.1 Check the unit when it is delivered. Any damage should be immediately reported to the company. 4.2 Check the oil level before starting up. 4.3 Turn the machine on only if you are close to it. - Page 8 5.1.10 Maintain your compressor with care. 5.1.10.1 Keep your compressor clean. 5.1.10.2 Follow the maintenance instructions. 5.1.10.3 Regularly check the plug and electrical supply lead. 5.1.10.4 Any damaged parts should be dealt with by a qualified person. 5.1.10.5 Inspect extension supply leads periodically and replace them if they are found damaged.
- Page 9 There will be a risk of inhaling noxious fumes, mists and vapours. 5.2 Safety instructions for the operation of the compressed air and blow guns. 5.2.1 The compressor reaches a high temperature during operation. Touching it when hot can lead to burns. 5.2.2 The compressor must not be allowed to take in impurities in the air;...
-
Page 10: Installation & Comissioning
6. INSTALLATION & COMISSIONING. Before commissioning, all parts should be completely installed. 6.1 Installation of the wheels and foot. 6.1.1 Select parts as shown in image below (1). 6.1.2 Assemble as shown in (1)(2) by taking bolt (a) and pushing it through the centre hole of wheel (b), then put washer over protruding bolt (a). - Page 11 6.2 Installation (replacing) of the air filter. 6.2.1 .1 Remove the shipping plug (Picture 4) with a screwdriver or a similar tool. Unscrew the air filter (1) with the wing nut (a) attached to the machine (Picture 5). 6.3 Filling with oil. 6.3.1 Use a screwdriver to remove the oil filler cap (Picture 6 (a)) and fill with oil into machine as shown (b) in the oil filler (Picture 7).
-
Page 12: Technical Data
7. TECHNICAL DATA. 7.1 Technical data for HY2524. Model HY2524 Voltage - V Number of phases Frequency – Hz Connection method/Cable length m 3 pin plug - BS1363A/1.3 Motor power hp/kw 2.5/1.865 Rated Speed (motor) – RPM 2800 Cubic Foot per Minute @ 6.2 Bar... - Page 13 8.2 Condensation. Condensation inside the tank may contain the oil residues. Dispose of the condensation in an environmentally friendly way. DO NOT put it down the drain or onto the ground. 8.2.1 You MUST remove condensed water is daily. 8.2.2 This can be achieved by opening the condensation drain plug at the bottom of the compressor.
-
Page 14: Disposal & Recycling
9. DISPOSAL & RECYLING. 9.1 Do not dispose of electric equipment together with household waste material! In observance of European Directive 2012/19/EC on waste electrical and electronic equipment and its implementation in accordance with national law, electric equipment that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility. -
Page 15: Genpower Contact Details
11.3 3 Email contact; Techinical - service@genpower.co.uk 11.4 4 Web site; www.hyundaipowerequipment.co.uk 12. DECLARATIONS of CONFORMITY. 12.1 Genpower Ltd confirms that this Hyundai product conform to the following CE directives. 2002/95/EC Restriction of Hazardous Substances 2004/108/EC EMC Directive 2006/42/EC Machinery Directive... - Page 16 GENPOWER LTD Isaac Way, London Road Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 info@hyundaipowerequipment.co.uk www.hyundaipowerequipment.co.uk...
