Wing Struts
3
Screw
M3 x 15mm
12
d
xD7
Washer
3
mm
16
M3
Nut
4
Plastic Wire Bracket
M3 Nut
4
Stabilizer & Elevator
Vertical Fin & Rudder
5
Main Wing Strut
M3x15mm
(Stabilizer)
B
B'
(Main Wing)
B=B'
Pre-glued
P.4
69mm
193mm
380mm
Washer d3xD7mm
M3 x 15mm
Bottom View
Temporary install the main wing, adjust
leveling of the stabilizer to make it as
parallel to the main wing as possible.
COMPLETED
COMPLETED
69mm
202mm
369mm
d3xD7mm
Washer
C
C
C
C
Pre-glued
