2
Chapter 1 Product description
Description
●
Intel Wireless-N 7260BN 802.11 b/g/n 2×2 WiFi + BT 4.0 Combo Adapter
Integrated wireless wide area network (WWAN) options by way of wireless module
Two WLAN antennas built into tablet
Support for the following WWAN formats:
●
HP hs3110 HSPA+ Mobile Broadband Module
●
HP lt4112 LTE/HPSA+ Mobile Broadband Module
Accelerometer
Ambient light sensor (ALS)
Digital compass
Gyroscope
Near field communication (NFC)
HP multiformat Micro Digital Media Reader Slot with push-push technology. Reads data from and
writes data to digital memory cards such as Secure Digital (SD).
Tablet:
●
Audio: one combo audio-out (headphone)/audio-in (microphone) jack, supports Beats
audio, voice recognition, and jack auto-detection
●
Docking connector: supports keyboard base capabilities (charging, audio-out, and video-
out)
Keyboard base:
●
Audio: one combo audio-out (headphone)/audio-in (microphone) jack, supports Beats audio
and voice recognition yes
●
Docking connector: supports keyboard base capabilities (charging, audio-out, and video-
out) yes
●
HDMI: v. 1.4, supporting up to 1080p at 60 Hz yes
●
RJ45/Ethernet
●
USB: USB 3.0 (2) yes
●
Video: VGA (Dsub 15-pin) supporting 1920×1200 external resolution at 60 Hz, hot plug/
unplug and auto-detection for correct output to wide-aspect vs. standard aspect video
Full-size, island-style keyboard (no numerical keypad)
Clickpad with image sensor
Clickpad requirements:
●
MultiTouch gestures enabled
●
Taps enabled as default
Support for the following AC adapters:
●
65-W HP Smart AC adapter (non-PFC, 4.5-mm)
●
65-W HP Smart AC adapter (non-PFC, EM, 4.5-mm)
Support for a 3-cell, 32-Wh, 2.96-Ah, Li-ion battery for use only in the tablet (includes cable)
Support for a 3-cell, 33-Wh, 3.05-Ah, Li-ion battery for use only in the keyboard base
(includes cable)
