A selection of glues - SIG Thin and Thick CA and
SIG Kwik-Set 5-Minute Epoxy
Threadlock Compound,
Silicon Sealer - clear or white tub and shower type
Screwdriver Assortment
Pliers - Needle Nose & Flat Nose
Diagonal Wire Cutters
Small Allen Wrench Assortment
Pin Vise for Small Dia. Drill Bits
Hobby Knife With Sharp #11 Blades
Scissors
Heat Iron and Trim Seal Tool
Masking Tape
Paper Towels
Glass Cleaner,
such as SIG Pure Magic Model Cleaner or Windex
Power Drill With Selection of Bits
Dremel
®
Tool With Selection of Sanding and Grinding Bits
Soldering Iron and Solder
Large Fuel Tubing
COMPLETE KIT PARTS LIST:
The following is a complete list of all parts contained in this kit.
Before beginning assembly, we suggest that you take the time to
inventory the parts in your kit, using the provided check-off boxes
(
). Note that the CA type hinges for the ailerons, rudder, and
elevators are in place in each of these parts but are not yet glued
in place. Also, note that the nuts and bolts required to mount your
engine to the motor mounts are not included in this kit and must be
purchased separately.
BASIC AIRCRAFT PARTS:
1 each Right Wing Panel With Aileron in Place With
4 CA Hinges - Not Glued Aileron Servo Cable String
Installed - Factory Covered
1 each Left Wing Panel With Aileron in Place With
4 CA Hinges - Not Glued Aileron Servo Cable String
Installed - Factory Covered
1 each Vertical Fin & Rudder Assembly With
4 Hinges - Not Glued Factory Covered
1 each Horizontal Stabilizer & Elevator Assembly With
6 Hinges - Not Glued Factory Covered
1 each Fuselage With Clear Plastic Windshield Installed
With 7 Screws. 4 Landing Gear Blind Mounting Nuts
Installed, Installed 1/4-20 Blind Mounting Nuts For
Wing Attachment, 2 Wing Strut Attachment Blind Nuts
Installed, Pull-Pull Exits Installed - Factory Covered
SUB ASSEMBLIES:
1 bag
Fiberglass Cowl, White:
4 each
#3 x 10mm PWA Mounting Screws
1 bag
Fiberglass Wheel Pants - 1 Right, 1 Left - Factory
Painted (Blue/White or Red/White) With Blind
Mounting Nuts Installed (2 per pant) for Mounting
1 bag
3" Dia. White SIG Spinner Assembly:
1 each
Spinner Cone
1 each
Spinner Backplate
1 each
Prop Adapter Ring Set
4 each
#2 x 10mm Phillips Head Mounting Screws
1 bag
Molded Clear Plastic Side Window Set
1 bag
Motor Mount Assembly:
2 each
Fiber-Filled Motor Mount Arms - 1 Right, 1 Left
4 each
M4 x 25mm PWA Mounting Bolts
Such as Loctite
®
Non-Permanent Blue
4 each
4 each
4 each
1 bag
Fuel Tank Assembly:
1 each
1 each
1 each
1 each
1 each
1 each
1 each
3 each
®
1 @ 40mm Long
1 @ 50mm Long
1 @ 60mm Long
1 bag
SIG Tailwheel Assembly - Medium:
1 each
1 each
1 each
2 each
3 each
2 each
1 bag
Main Landing Gear Assembly:
1 each
2 each
2 each
4 each
2 each
2 each
4 each
4 each
4 each
4 each
1 bag
Wing Strut Assemblies:
1 each
1 each
4 each
4 each
4 each
1 bag
Aileron Servo Hatch Assemblies & Wing Bolts:
1 each
1 each
4 each
8 each
4 each
2 each
3
M4 Washers
M4 Split Ring Lock Washers
M4 Blind Mounting Nuts
450cc (15.2 oz.) Fuel Tank
Fuel Pick-Up "Clunk" - Metal
4-1/2" Length of Fuel Tubing (for glow
engines only)
Rubber Fuel Tank Stopper (for glow
engines only)
Front Stopper Compression Plate
Rear Stopper Compression Plate
M3 x 18mm Phillips Head Compression Bolt
3mm Dia. Aluminum Tube Fuel Lines:
Main Tailwheel Spring Arm With Steering
Arm & 1-1/4" Dia. Tailwheel Installed
Secondary Tailwheel Spring Arm
2-Arm Rudder Steering Plate - Metal
#2 X 10mm PWA Steering Plate
Mounting Screws
#3 x 15mm PWA Tailwheel Assembly
Mounting Screws
Centering Springs
Landing Gear, 4mm Hardened
Aluminum – Factory Painted White
3-1/2" Dia. Main Wheels - "Lite"-Type
M5 x 50mm Hardened Steel Allen Head
Axle Bolts
M5 Hex Nuts
M5 Split Ring Lock Washers
M5 Brass Spacer Sleeves
M4 x 20mm PWA Main Landing Gear
Mounting Bolts
M4 Split Ring Lock Washers
M3 x 12mm Phillips Head Wheel Pant
Mounting Bolts
M3 Split Ring Lock Washers
Right Wing Strut, Aluminum, With
Contoured End Caps Installed -
Factory Painted White
Left Wing Strut, Aluminum, With
Contoured End Caps Installed -
Factory Painted White
M3 x 20mm Allen Head Mounting Bolts
M3 Washers
M3 Split Ring Lock Washers
Right Aileron Hatch, Plywood - Factory
Covered
Left Aileron Hatch, Plywood - Factory
Covered
10mm x 20mm sq. (3/8" x 3/4" sq.)
Hardwood Aileron Servo Mounting Blocks
#3 x 10mm PWA Servo Hatch Mounting
Screws
#2 x 8mm PWA Mounting Block Screws
1/4-20 x 1-1/2" Nylon Wing Mounting Bolts
