This chapter gives a detailed explanation of the hardware
features onboard the SBC8168 all-in-one Socket 370 CPU card.
4.1

Microprocessors

The SBC8168 supports Intel Celeron or Pentium III CPUs.
Systems based on these CPUs can be operated under UNIX,
OS/2, Linux, Windows NT/2000, Windows 95/98/Me and MS-
DOS environments. The system's performance depends on the
installed CPU on the board. When installing a new CPU, the
jumpers including CPU type, CPU Clock, CPU Voltage and Bus
Clock may need to be adjusted. Make sure all the settings are
correct for the installed CPU to prevent any damage to the
CPU.
4.2

BIOS

The system BIOS used in SBC8168 is Award Plug and Play
BIOS. The SBC8168 contains a single 4Mbit Flash EPROM.
For more detailed information, refer to Chapter 7 for a
complete description of the BIOS setup utility and the available
features accompanying it.
