SBC8168 Socket 370 All-in-One CPU Card Series User's Manual
7.3

Standard CMOS Features

"Standard CMOS Setup" allows you to record some basic
hardware configurations in your computer system and set the
system clock and error handling. If the motherboard is already
installed in a working system, you will not need to select this
option. You will need to run the Standard CMOS option,
however, if you change your system hardware configurations,
the onboard battery fails, or the configuration stored in the
CMOS memory was lost or damaged.
CMOS Setup Utility-Copyright © 1984-2000 Award Software
Standard CMOS Features
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Primary Master
IDE Primary Slave
IDE Secondary Master
IDE Secondary Slave
Drive A
Drive B
Floppy 3 Mode Support
Video
Halt On
Base Memory
Extended Memory
Total Memory
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
At the bottom of the menu are the control keys for use on this
menu. If you need any help in each item field, you can press
the <F1> key. It will display the relevant information to help
you. The memory display at the lower right-hand side of the
menu is read-only. It will adjust automatically according to the
memory changed. The following pages describe each item of
this menu.
Award BIOS Utility
Mon, Feb 21 2000
2 : 31 : 24
Menu Level
Press Enter None
Press Enter None Change the
Press Enter None Day, month,
Press Enter None Year and
century
1.44M, 3.5 in.
None
Disabled
EGA/VGA
All, But Keyboard
640K
63488K
64512K
Item Help
