SBC8168 Socket 370 All-in-One CPU Card Series User's Manual
Ethernet 2: (optional)
Intel 82559 PCI Bus 10/100M Base-T
Onboard Wake On LAN (via ATX power supply)
Onboard RJ-45 connector
USB Interface:
IrDA: 1 IrDA pin-header for wireless communication
Power Management:
Hardware Monitoring:
Watchdog Timer:
Generates System Reset or Non-Maskable Interrupt (NMI) via
jumper selection
64 programmable time interval levels of 0.5~8/5~80/50~800/
100~1600 seconds
SSD: Supports M-Systems DiskOnChip 2000 series
Power Consumption:
+5V @10A, +12V @200mA)
®
(Pentium III 850MHz, 256MB SDRAM)
Other Features:
Keyboard/Mouse Wakeup (via ATX power supply)
Modem Ring-on (via ATX power supply)
STR (Suspend-to-RAM) via ATX power supply
Operating Temperature:
Storage Temperature:
Operating Humidity: 5%~95%; non-condensing
Storage Humidity:
Dimensions:
NOTE:
Specifications are subject to change without
notice.
1.3

Utilities Supported

Intel Chipset Driver
Ethernet Utility and Drivers
Introduction
4 USB ports; USB Spec. Rev. 1.1
compliant
ACPI
ITE 8712F controller,
monitoring for CPU temperature,
system voltage, and fan speed
o
0 C~60
o o
20 C~85
5%~75%
122(W) x 335(L) mm
o o o
C (32 F~140 F)
o o
C (-4 F~185 F)
3
