System board components

The following figure and table describe the system board component layout.
1
Internal USB
2
Rear DP/LAN
3
Rear USB
4
Rear audio
5
Side I/O
6
Touch controller header
SATA
7
Hard drive SATA (6 Gb/s)
8
Optical drive SATA (6 Gb/s)
PCI/PCIe
9
Mini PCIe/mSATA (2)
10
MXM graphics
6
Chapter 1 Hardware overview
I/O
11
12
13
14
15
16
17
18
19
20
21
22
23
Cooling
CPU fan
Memory fan
MXM fan
Power
Battery
Main power
Optical drive power
User panel I/O header
HDD power connector
Service
Clear CMOS
Crisis Recovery jumper
ME/AMT flash override jumper
Boot block enable
Password jumper
Misc
24
Display
25
Hood sensor
26
LED backlight
27
Speakers
28
Webcam/Mic
29
Thunderbolt 2 module PCIe
30
Thunderbolt 2 module DisplayPort
31
Thunderbolt 2 module power
32
Side I/O memory card reader
33
Side I/O USB 3.0
34
Side I/O USB 3.0 battery charging
35
Side I/O audio (headset)
36
Side I/O audio (mic)
