Control Throws

Rudder
Elevator
21
C.G.
The ideal C.G. position is 85mm (3.35in.) behind the leading edge measured at where the wing meets the
fuselage. In order to obtain the C.G. specified, add weight to the fuselage or move the battery position.
Check the C.G. before flying.
If you are converting this model to electric, please move the C.G. forward 10% of current C.G. distance from
leading edge to compensate for weight of fuel.
Warning!

Important Safety Precautions

# First time flyer should never fly by himself / herself. Assistance from experienced flyer
is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly
pre-adjusted aircraft.
SkyLink 40
#
more powerful engine does not mean better performance. In fact, over powered engine
may cause structural damage and injuries.
# Make sure the air field is spacious, never fly the plane too close to people and never
get too close to a running propeller.
# If you find wrinkles on the covering as a result of weather changes, you can use hot iron
to remove the wrinkles. Please begin with lower temperature setting and gradually raise
the temperature until the wrinkles are gone. Too hot an iron may damage the covering.
Don't use hot iron near the seams or edges, hot iron will melt the glue and shrink the covering
at the same time, causing the seams to pull away.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
A246PO28151211
20mm
20mm
Flaps (near fuselage)
85mm
3.35 in
C.G.
is specially designed to be powered by
Adjust the control throws as shown in
the diagram. These throws are good for
general flying. You can adjust according
to your personal preference.
20mm
20mm
Ailerons (away from fuselage)
http://www.theworldmodels.com/para/instruction/instructionManuals.php
2C 0.40-0.55
P.12
18mm
12mm
12mm
engine, using a
