Directory structure of the FTP server

The files accessible via FTP are found in several folders:
Folder name
execute
system
Display of the following folders depends on the installed memory media
and the defined default card slot:
card
cf
cfext
iffs
pccard
usbmem
Pronto! 482/486/682/863
Contents
Printing of label files stored in this folder is started
immediately. The files must be of the type .LBL. The
corresponding file is deleted once the print job is
complete.
Firmware file of the printer
Data of the memory medium in the default card slot.
The structure of the folder depends on the medium type.
Data of the CompactFlash memory card in the printer if
the CF card slot is not default. The files are separated
into several subfolders accordingly based on their type.
When copying the files to the "cf" folder, type-based
sorting occurs automatically in the subfolders.
Data of the CompactFlash memory card in the external
operating panel if the external card slot is not default.
The files are separated into several subfolders
accordingly based on their type.
Contents of the IFFS (Internal Flash File System). When
logging on with the username "root", the contents of the
IFFS can be managed.
Data of the PC card if the card slot is not primary. This
folder does not have a substructure.
Data of the USB flash drive if the USB flash drive is not
default. The files are separated into several subfolders
accordingly based on their type. When copying the files
to the "cf" folder, type-based sorting occurs
automatically in the subfolders.
14-3
