Printer Status Line Tab - QuickLabel Systems pronto! 486 User Manual

Column
E-mail
Sound
Note: The settings are not accepted until the Transfer button is clicked. If you
switch to another tab beforehand, the settings are lost.

Printer status line tab

On the "Printer status line" tab, you can select the status parameters (widgets)
which are to be displayed on the printer status line.
Adding a status parameter:
1 Select widget in pull-down menu. Note the text color:
• pale green: Widget may be added
• pale red: Widget may only be added, if another widget is deleted
• black: Widget is already activated
Pronto! 482/486/682/863
Meaning
Valid e-mail address for the SMTP server to which the
message is to be sent.
• Click cell and enter e-mail address or select from
pull-down menu.
Audible signal which indicates receipt of the message.
• Click cell and select signal type in pull-down
menu.
5-21
