WLAN-Card

Function

The WLAN-card 802.11 b/g allows to link a printer to a wireless network
which contains a Wireless Access Point. The ad-hoc mode for direct
connection between several end devices is not supported.
Note: When using the WLAN-card the printer port for the wired Ethernet
connection is disabled!

Mounting

Slide the WLAN-card (1) considering the correct orientation of the two-rail
guide (3) into the PC Card slot (2) until it stops.
Note: The function Test > WiFi status allows to print a list (4) of the accessible
Wireless Access Points. For the printout material must be loaded which
extends across the entire printing width.
8-56 Accessories
