• Slide the flange (3a) on the winding axle (2) so that the attachment of the
flange points to the outside.
• Align the flange (3a) so that the screw (10) grasps into the groove (11) of
the winding axle (2). Tighten the screw (10) in the flange.
• Slide the material roll (12) onto the axle until it touches the flange slightly.
• Push the second flange (3b) with the attachment outside onto the axle
until it touches the material roll.
Note: Align the second flange (3b) to the first flange (3a)!
If the material roll is smaller than the spring on the axle, ensure that the
spring on the axle is guided in the groove of the flange. If necessary align
flange (3a) to flange (3b)!
• Tighten the knurled screw (13) in the flange (3b).
Now you can continue with the Insertion of the Prepared Winding Axle on page
8-34.
