External Rewinder (ER1)

Label Width
Rewind Diameter
Core Diameter
Rewind Speed
Label Rewinding
Operating Temperature
Transport and Storage Temperature
Dimensions of the Rewinder
Height
Width
Depth
Weight
Pronto! 482/486/682/863
ER1: up to 4.7 in (120 mm)
max. 8.19 in (210 mm)
1.56 in (40 mm) on rewind axle
1.56 in (40 mm) on cardboard core
with adapter 3 in (76 mm) on
cardboard core
2 - 12 ips (50 - 300 mm/s)
Labels inside or outside
50°F - 95°F (10 bis 35°C)
at 10 - 85% humidity, non
condensing
4°F - 122°F (-20 bis 50°C)
at 10 - 85% humidity, non
condensing
11.0 in (280 mm)
9.8 in (250 mm)
11.1 in (285 mm)
9.9 lbs (4,5 kg)
17-3
