Page 1: Table Of Contents
TIMBERWOLF CONTENTS TW 13/75G Section Page No. INTRODUCTION PURPOSE OF MACHINE MACHINE DIMENSIONS & SPECIFICATIONS PARTS LOCATION DIAGRAMS SAFE WORKING Operator’s Personal Protective Equipment Required Basic Woodchipping Safety General Safety Matters - Do’s and Dont’s Noise Test OPERATING INSTRUCTIONS Safe Transportation Delivery Operator’s Personal Protective Equipment Required... -
Page 2: Introduction
- DAMAGE TO PROPERTY - A MEMBER OF THE GENERAL PUBLIC BECOMING INJURED This manual covers the operation and maintenance of the Timberwolf TW 13/75G. All information in this manual is based on the latest product information available at the time. -
Page 3: Purpose Of Machine
TIMBERWOLF TW 13/75G The Timberwolf TW 13/75G Designed to chip solid wood material up to 75mm in diameter and capable of chipping over 0.75 tonnes of brushwood per hour. DIMENSIONS Serial No. Location The serial number can be found on the identification plate located on the side of the rotor housing. -
Page 4: Parts Location Diagrams
TIMBERWOLF TW 13/75G PARTS LOCATOR GRIP DISCHARGE HANDLE DISCHARGE BUCKET TOP ROTOR HOUSING FUNNEL BELT GUARD PETROL TANK OPENING HANDLE AIR FILTER COVER ROTOR HOUSING CATCH BOLT ENGINE SAFETY SWITCH... - Page 5 TIMBERWOLF TW 13/75G PARTS LOCATOR BLADE ROTOR REAR BEARING HOUSING CUTTER BLADE ROTOR DRIVE PULLEY ENGINE PROTECTOR ENGINE PULLEY...
-
Page 6: Safe Working
TIMBERWOLF SAFE WORKING TW 13/75G WARNING The chipper will feed material through on its own. To do this, it relies on sharp blades both on the feed rollers and the chipper rotor. To keep the blades sharp, only feed the machine with clean brushwood. DO NOT put muddy/dirty wood, roots, potted plants, bricks, stones or metal into the chipper. -
Page 7: General Safety Matters - Do's And Dont's
TIMBERWOLF SAFE WORKING TW 13/75G GENERAL SAFETY MATTERS ü D O ’ S A N D D O N ’ T S ALWAYS stop the chipper engine before making DO NOT operate chipper unless available light is any adjustments, refuelling or cleaning. -
Page 8: Noise Test
TIMBERWOLF SAFE WORKING TW 13/75G NOISE TEST MACHINE: TW 13/75G NOTES: Tested chipping 40mm x 40mm corsican pine 1.5m in length Noise levels above 80dB (A) will be experienced at the working position. Wear ear protection at all times to prevent possible damage to hearing. All persons within a 4 metre radius must also wear good quality ear protection. -
Page 9: Operating Instructions
FACE MASK (if appropriate). HEAVY-DUTY gloves with elasticated wrist area. See page 5 for more detailed information. MANUAL CONTROLS There are five controls on the Honda GX 390 K1 that are required for daily usage of the TW 13/75G chipper. THROTTLE CONTROL LEVER... -
Page 10: Stopping The Engine
TIMBERWOLF OPERATING INSTRUCTIONS TW 13/75G STOPPING THE ENGINE MOVE the throttle control lever to idle and allow to run for one minute. TURN the fuel valve to the ‘OFF’ position. EMERGENCY STOPPING Turn the ignition switch to the 'Off' position (as shown above). -
Page 11: Blade Wear
“dull” change the blade(s). The TW 13/75G is fitted with one blade 177 mm (7") long. It is 43 mm wide when new. -
Page 12: Service And Maintenance
MAINTENANCE THAT SHOULD BE APPLIED TO ANY PIECE OF MECHANICAL EQUIPMENT AND THE CHASSIS TO WHICH IT IS MOUNTED. AUTHORISED TIMBERWOLF SERVICE AGENTS ARE FULLY TRAINED IN ALL ASPECTS OF TOTAL SERVICE AND MAINTENANCE OF TIMBERWOLF WOOD CHIPPERS. YOU ARE STRONGLY ADVISED TO TAKE YOUR CHIPPER TO AN AUTHORISED AGENT FOR ALL BUT THE MOST ROUTINE MAINTENANCE AND CHECKS. -
Page 13: Service Schedule
Replace anvil when worn. RETURN TO DEALER FOR ANVIL CHANGE NOTE: Your Timberwolf woodchipper is covered by a full 12 months parts and labour warranty. Subject to correct maintenance and proper machine usage, the bearings are guaranteed for 12 months regardless of hours worked by the machine. -
Page 14: 13 Service Instructions
Inspect the lifting eye prior to each use - DO NOT USE LIFTING EYE IF DAMAGED. SPARES Only fit genuine Timberwolf replacement blades, screws and chipper spares. Failure to do so will result in the invalidation of the warranty and may result in damage to the chipper, personal injury or even loss of life. -
Page 15: Change Blades
Rotor Retaining Pin (supplied in tool kit). Timberwolf recommend you purchase a torque wrench for this and other jobs on the Use a small screw driver to clean out the star chipper. -
Page 16: Check Fittings
TW 13/75G CHECK FITTINGS The Timberwolf TW 13/75G is subject to large vibrations during the normal course of operation. Consequently there is always a possibility that nuts and bolts will work themselves loose. It is important that periodic checks are made to ensure the security of all fasteners. Fasteners should be tightened using a torque wrench to the required torque (see below). -
Page 17: Warranty Statement
– in these situations they are duly authorised to transfer any remaining warranty period to their first end user. Any warranty offered by the Timberwolf Dealer beyond the original 12 month period will be wholly covered by said Dealer. -
Page 18: Ec Declaration Of Conformity Certificate
TIMBERWOLF 17 SERVICE INSTRUCTIONS TW 13/75G CERTIFICATE OF CONFORMITY... -
Page 19: Identification Plates
TIMBERWOLF SERVICE INSTRUCTIONS TW 13/75G... -
Page 20: 19 Decals
TIMBERWOLF 19 DECALS TW 13/75G DANGER HIGH VELOCITY DANGER DANGER DISCHARGE KEEP CLEAR! EXHAUST DANGER DANGER DANGER OPERATING INSTRUCTIONS DANGER READ THE INSTRUCTION MANUAL. BEWARE OF SHARP BLADES THE INSTRUCTION MANUAL WITH THIS MACHINE CONTAINS IMPORTANT OPERATING, MAINTENANCE AND WHEN THE HEALTH AND SAFETY INFORMATION. - Page 21 TIMBERWOLF DECALS TW 13/75G 671 - these individual decals are supplied as a set, they may not all apply to your machine.
- Page 22 (Blank)
-
Page 23: Parts Lists
TIMBERWOLF TW 13/75G PARTS LISTS The following illustrations are for parts identification only. The removal or fitting of these parts may cause a hazard and should only be carried out by trained personnel. Page No. CHASSIS / ROTOR HOUSING DECALS 19 &... - Page 24 TIMBERWOLF 23 CHASSIS/ROTOR HOUSING TW 13/75G Item Part No Part Name Q’ty 1567FO Front Plate 0644 M12 P Nyloc Nut 0702 M12 A Washer 0345 Capheads 0105MH Gravity Anvil 18452FO Main Rotor Housing 2475FO Chassis 0704 M12 C Washer 2476MS...
- Page 25 TIMBERWOLF ENGINE TW 13/75G Date Last Modified: 5th Oct 2012 Item Part No Part Name Q’ty Item Part No Part Name Q’ty Fuel Cap 18960M Rotor Shaft Key supp’d with engine Spark Plug 4280M Rear Shaft supp’d with engine Air Filter...
- Page 26 TIMBERWOLF 25 FUNNEL/DISCHARGE TW 13/75G Date Last Modified: 24th Jan 08 Item Part No Part Name Q’ty Item Part No Part Name Q’ty 1642FO Funnel 0712 M8 C Washer 0134 Plastic Grip 0318 M12/20 Bolt 1052FO Discharge Bucket 2000FB Belt Guard...
- Page 27 TIMBERWOLF ROTOR TW 13/75G Date Last Modified: 10th Sept 09 Item Part No Part Name Q’ty Item Part No Part Name Q’ty 17342M Rotor 0648 Bearing Front SFT25 17317F Fan Blade 0796 20 thou Shim As Req’d 0701 M10 A Washer...
- Page 28 TIMBERWOLF V-BELT TENSIONING TABLE TW 13/75G...
