TTR assist
roller
Tear bar
Drive
roller

Tools for Cleaning the Printer

EasyCoder 4420 and 4440 Bar Code Label Printer User's Manual
C d 39
Helvetica Condensed
Fee
d/Pa
u se
Power/D
ata
Alert
Empty/P
ause
Printer parts: This illustration shows the printer parts that need to be cleaned. For a
maintenance schedule of each part, see the Printer Maintenance Schedule table earlier
in this chapter.
To clean the printer safely and effectively, use these items:
*• Cleaning card (P/N 1-110501-00)
*• Cotton swabs
*• Isopropyl alcohol
*• Clean lint-free cloth
*• Soft bristle brush or vacuum cleaner
*• Soapy water or mild detergent
The following procedures explain how to access the printer parts and clean
them without causing any harm to the printer or yourself.
Chapter 3 — Maintaining the Printer
Edge
guide
Thermal
printhead
Upper media
guide
Lower media
guide
44XXU035.eps
31
