TVLogic LQM-071W Operation Manual

TVLogic LQM-071W Operation Manual

7” integrated multi format hd quad input monitors
Hide thumbs Also See for LQM-071W:

Advertisement

Quick Links

Download this manual
Multi Format

LCD MONITOR

Operation Manual

7" Integrated multi format HD Quad input monitors
LQM-071W
MULTI

Advertisement

loading
Need help?

Need help?

Do you have a question about the LQM-071W and is the answer not in the manual?

Questions and answers

Related Manuals for TVLogic LQM-071W

Summary of Contents for TVLogic LQM-071W

  • Page 1: Lcd Monitor

    Multi Format LCD MONITOR Operation Manual 7” Integrated multi format HD Quad input monitors LQM-071W MULTI...

  • Page 3: Table Of Contents

    Contents CAUTION CAUTION CAUTION ..................FEATURES FEATURES FEATURES ..................NAME & FUNCTION OF EACH PART NAME & FUNCTION OF EACH PART NAME & FUNCTION OF EACH PART ............OSD MENU ORGANIZATION OSD MENU ORGANIZATION OSD MENU ORGANIZATION ..............PRODUCT SPECIFICATION PRODUCT SPECIFICATION PRODUCT SPECIFICATION ..............

  • Page 4: Caution

    Caution LQM-071W LQM-071W LQM-071W ALWAYS USE SET VOLTAGE. AC 100 ~ 240V (1.2A/50~60HZ), DC 12/24V (MAX 6A) All operating instructions must be read and understood before the product is operated. These safety and operating instructions must be kept in safe place for future reference.
  • Page 5 Caution LQM-071W In case the product needs replacement parts, make sure that the service person uses replacement parts speci ed by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in re, electric shock and/or other danger.

  • Page 6: Features

    Features LQM-071W LQM-071W HAS THE FOLLOWING FEATURES: 4 x SDI Inputs. 4 x Analog CVBS Inputs. (Share BNC with SDI input) HD-SDI, SD-SDI, CVBS Auto detect. 1 x SDI Output. Embedded Audio Level Meter Built in audio disembedder and internal speakers...

  • Page 7: Name & Function Of Each Part

    Name & Function of Each Part LQM-071W LQM-071W LQM-071W FRONT TALLY LY L DISPLAY DISPLAY DISPLAY DISPLAY DISPLAY DISPLAY DISPLAY BRIGHT BRIGHT BRIGHT BRIGHT BRIGHT BRIGHT BRIGHT CHROMA MARKER CHROMA MARKER CHROMA MARKER CHROMA MARKER CHROMA MARKER CHROMA MARKER CHROMA MARKER...
  • Page 8 Name & Function of Each Part LQM-071W LQM-071W LQM-071W 2. BUTTON FUNCTION [MODE] - Used to select display mode. (See Chart 2.) [CH SEL] - Used to select active input channel. [BRIGHT] - Used to control the brightness of the selected input display.
  • Page 9 INPUT 1. SDI IN/OUT [SDI/CVBS INPUT] HD-SDI. SD-SDI, CVBS Signal input terminal. - LQM-071W detects input source automatically and displays the source format for HD-SDI, SDI and “NTSC” or “PAL” for CVBS. [SDI OUTPUT] SDI output terminal. - If the selected input channel is in HD-SDI, the output is in HD-SDI and if the selected input channel is in SD-SDI input channel, the output is in SD-SDI.
  • Page 10 Name & Function of Each Part LQM-071W 3. DC IN DC 12V power input. 4. REMOTE Provides connection to monitor control equipment via simple GPI contact closure. 5. COMMUNICATION [FACTORY PGM] REMOTE (RJ-45) Input connector for FACTORY PGM allowing for rmware updates.

  • Page 11: Osd Menu Organization

    OSD MENU Organization LQM-071W 1. MENU CONTROL PICTURE BRIGHT COLOR CONTRAST CHROMA MARKER PEAKING ASPECT RATIO REMOTE INT PATTERN DISPLAY SYSTEM - User can control the features of the monitor using the Menu. - To control the Menu, use MENU button, MENU ENCODER and MENU ENC SW.
  • Page 12 OSD MENU Organization LQM-071W 3) CHROMA - Application : For each input channel. - Value Range : -50 ~ 49 - Default Value : 0 - Function : Controls the saturation of the selected input display. 4) PEAKING - Application : For each input channel.
  • Page 13 OSD Menu Contents LQM-071W 4) GAIN BLUE - Application : For all available inputs. - Value Range : -50 ~ 49 - Default Value : Color calibration Value (No default value for custom1/2/3) - Function : Controls gain value of Blue.
  • Page 14 OSD Menu Contents LQM-071W 4) SAFETY AREA - Application : For each input channel. - Value Range : “OFF” , “80%” , “88%” , “90%” , “93%” , “98%” , “USER” - Default Value : “OFF” - Function : Selects the Safety Area Marker type for selected channel.
  • Page 15 OSD Menu Contents LQM-071W [4] REMOTE PART <REMOTE Function List> Display Function NONE No REMOTE function assigned. R TLY C1 RED TALLY ON for CH1 R TLY C2 RED TALLY ON for CH2 R TLY C3 RED TALLY ON for CH3...
  • Page 16 OSD Menu Contents LQM-071W 4) PIN4 - Application : For all available inputs. - Value Range : See Chart 1. - Default Value : “R TLY C4” - Function : Selects function for REMOTE PIN4. 5) PIN5 - Application : For all available inputs.
  • Page 17 OSD Menu Contents LQM-071W <4P> <4P1W1V> WAVEFORM <4P3W> <3P1W> WAVEFORM WAVE Y WAVE Cb WAVE Cr <3P1V> <2P1W1V> VECTOR WAVEFORM VECTOR...
  • Page 18 OSD Menu Contents LQM-071W <2P2W> <2P2V> WAVEFORM WAVEFORM VECTOR VECTOR <1P> <1P1W> WAVEFORM <1P1W1V> <1P3W> WAVEFORM WAVE Y WAVE Cb WAVE Cr...
  • Page 19 OSD Menu Contents LQM-071W 1) DISP MODE - Application : For all available inputs. - Value Range : “4P” , “4P1W1V” , “4P3W” , “3P1W” , “3P1V” , “2P1W1V” , “2P2W” , “2P2V” , “1P” , “1P1W” , “1P1W1V” , “1P3W”...
  • Page 20 OSD Menu Contents LQM-071W <SRC ID String ASCII Characters> “SPACE” ! " # $ % & ' ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @...
  • Page 21 OSD Menu Contents LQM-071W 4) AUDIO GROUP - Application : For each input channel. - Value Range : “GR1” , “GR2” , “GR3” , “GR4” - Default Value : “GR1” - Function : Selects the embedded Audio Group of each display input. Selected Audio Group is used for the Audio Level Meter display and Embedded Audio Group for the audio output.
  • Page 22 OSD Menu Contents LQM-071W 9) KEY FUNC1 - Application : For all available inputs. - Value Range : See Chart 4. - Default Value : “AUDIO GROUP” - Function : Selects the F1 button function. 10) KEY FUNC2 - Application : For all available inputs.

  • Page 23: Product Specification

    Product Speci cation LQM-071W 4 x BNC SDI A/B/C/D Channel Input Input Analog Composite A/B/C/D Channel Input (Share BNC with SDI Input) Output 1 x BNC SDI A/B/C/D Channel Selected Output Analog Composite AD Converted Output Analog Composite Input Signal 1.458Gbps...

  • Page 24: Product Lineup

    Developed by FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.co.kr #914 Ace Techno Tower 9, 345-30 Gasan-dong, Geumcheon-gu, Seoul, 153-782, KOREA : +82 - 2 - 2026 - 1333 Fax : +82 - 2 - 2026 - 1339 Email: support@tvlogic.co.kr Digital Broadcasting System...
