Thanks for purchasing RVS-300/RVS-300G Black Box, a driver recording system.
Please be sure to read this manual in details before use.
We do not provide a warranty for the compatibility of some accessories which are not provided by us. We are also not responsible
for any defect caused by such accessories.
After getting the warranty card, please check the purchasing data (Date, Shop Info)on it.
Rear View Safety Viewer Program which is provided is designed to be run on Window 2000/XP/Vista.
it's product statement and caution(or attention) is below a user manual or instruction manual because Type label is too
small(No room for this writing) and required text is already included in the user guide
¤Statement (1)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions;
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may cause undesired operation.
¤Statement (2)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, users, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the userwill be required to correct the interference at his
own expense.
¤Warning
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFI-
CATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIP-
MENT
¤Caution
Danger of explosion if battery is incorrectly replaced. replace only with the same or equivalent type.
¤Information
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in
accordance with FCC multi-transmitter product procedures. And also used for this transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Hereby, the manufacturers declare that this VIDEO CAR BLACKBOX is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Warning!
Road Eye is a device to assist a safety driver.
We are neither responsible nor compensate for any defect and damage
caused by user's misuse and carelessness.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVS-300 Black Box and is the answer not in the manual?

Questions and answers

Summary of Contents for Rear view safety RVS-300 Black Box

  • Page 1 After getting the warranty card, please check the purchasing data (Date, Shop Info)on it. Rear View Safety Viewer Program which is provided is designed to be run on Window 2000/XP/Vista. it’s product statement and caution(or attention) is below a user manual or instruction manual because Type label is too small(No room for this writing) and required text is already included in the user guide ¤Statement (1)
  • Page 2: Table Of Contents

    Table of Contents Product Introduction Precautions for Safety Product Cautions in use Specifications Introduction Package Contents Part Descriptions LED Signal Descriptions Cautions before installation Installation Installation Guide Mounting Guide & Checkups after installation Function Installation of an external camera (Option) Function Descriptions Descriptions Start...
  • Page 3 Play through TV Cable connection for TV Out Playback File Viewer Mode Function of each key Playback the file recorded on Normal Mode Playback the file recorded on Event Mode Play through PC Viewer Program Installation Codec Installation How to use Viewer Program Playback video file Configuration Set Firmware Update...
  • Page 5: Product Introduction

    Product Introduction Product Introduction Precautions for Safety Cautions in use Specifications Package Contents Part Descriptions LED Signal Descriptions...
  • Page 6 Product Introduction RVS-300 is a Driver Recording System which applies GPS (Global Positioning System) GPRS/GSM (Option) and 3D acceleration gravity sensor (G-Sensor) Before using this product, please be sure to read this manual. Actual product specifications may differ from what is indicated in this manual as product enhancements are implemented without prior notice.
  • Page 7 Product Introduction Cautions in Use Cautions Performing while driving can be a cause of accident. Always park the car in a safe place first before operating the device. Check the installation status before driving. Driving under the physical conditions such as uneven, a sharp curve in the road with unstable installation might cause damage.
  • Page 8 Product Introduction Specification Front Camera 120° ” CMOS 300K Pixel Digital Sensor / WDR Support External Camera Option (90° ¼” CCD 270K Pixel NTSC) H.264 (VGA 640*480 up to 30fps) Recording Resolution 2ch use : VGA 640x480 up to 15fps Shock GPS Internal GPS Shock Sensor...
  • Page 9 Product Introduction Please check the contents after opening the gift box. Package Contents (Refer to the below images) RVS-300 (Or RVS-300G) Cigar Jack Power Cable A/V Cable User Manual (For TV Connection) Cable Tie / Holder Viewer Program CD SD Memory Card External Camera &...
  • Page 10: Part Description

    Product Introduction PART DESCRIPTION RVS-300 12 11 Front Camera Emergency Button SD Card Slot Mode Selection Switch 1. A/V : TV Out : External Camera Function Key Reset Key Mike Main Power Jack (Power TV Out Jack /External Camera Video In Jack (A/V Mode) (External Camera Mode) External Camera Jack (Power...
  • Page 11: Led Signal Descriptions 1

    Product Introduction LED Signal Descriptions GREEN YELLOW BLUE Classification Status (Event) (Full Time) (GPRS) (GPS) Power connecting Blinking at 1 sec interval one after another. (With SD Card) Power Connecting Blinking at 0.5 sec interval by turns (Without SD Card) Stand by Event Recording Blinking at 1 Sec interval When Event occurs...
  • Page 13: Installation Guide

    Installation Guide and Function Description Precaution Installation Mount Checkups after Installation External Camera Installation (Option) Function Description Start Event Record Mode Normal Record Mode (Full Time Recording) Reset GPS Function Acceleration Sensor Calibration G-Sensor Data analysis (Example) GPRS Function (Only for JS-300G) GPRS Configuration (Only for JS-300G)
  • Page 14 Installation Guide & Function Descriptions PRECAUTIONS Turn off the engine before installation. Connect the main power of the device at last after installation. , here in after called “Power”) Insert SD Memory card before connecting the device. Install the device in safe and bright place Connect the main power through cigar jack provided (DC 12V ~ 24V).
  • Page 15 Installation Guide & Function Descriptions Installation Attach the device Fix the device Get the camera lens focused on the front and fix with Lock Screws of the device. GPS reception part should be exposed to the window for the better reception. Connect the power Connect the cigar jack to the power port and check if the power is working properly.
  • Page 16 Installation Guide & Function Descriptions External Camera Installation (Option) Select a place to install Select a place to install the external camera and fix with the screw provided. (The connecting part should be toward to the ground.) Connect the camera to RVS-300 / RVS-300G Connect the camera to RVS-300 with the cable provided.
  • Page 17: Start 1

    Installation Guide & Function Descriptions Start Insert SD Card into RVS-300 / RVS-300G, then power on. Red, Yellow Blue LED will light sequentially at a second interval. About 3 seconds after lighting, RVS-300 / RVS-300G will start running. If it powers on without SD Card, Green LED will be blinking alternately at 0.5 sec interval.
  • Page 18: Reset 2

    Installation Guide & Function Descriptions Normal Record Mode (Full Time Recording) Green LED is blinking at a second interval on Normal Record Mode. 2. Normal Record Mode records video and audio at 5 minute interval successively. 3. If SD Card storage is full during Normal Mode, RVS-300 / RVS-300G will over- write starting from the file saved first.
  • Page 19 Installation Guide & Function Descriptions Acceleration Calibration Function If GPS data is not received properly, Blue LED will blink at one second intervals. When GPS Data reception is working properly, Blue LED will be lit continuously. If the Play Key is pressed during either Normal Record Mode or Event Record Mode for more than 3 seconds, GPS Cold Start will be operated with Blue LED blinking rapidly at...
  • Page 20 Installation Guide & Function Descriptions G- Sensor Data Analysis (Example) Viewer Program shows G-Sensor Data Graph as the below images upon Log Data which is saved with video files and driving status can be analyzed through the graph. time Stop time time Acceleration...
  • Page 21: Gprs Functions 2

    Installation Guide & Function Descriptions GPRS Functions (GPRS Function is only for RVS-300G) GPRS Specification Quad-band EGSM 850 / 900 / 1800 / 1900 MHz Output power - Class 4 @850 / 900 MHz (2W) - Class 1 @ 1800 / 1900 MHz (1W) Sensitivity - 107 dBm...
  • Page 22: Gprs Configuration Set 2

    Installation Guide & Function Descriptions GPRS Configuration Set Click Configuration Setting button, on RVS-300 Viewer Program. Then, click GPRS Tap and the below GPRS Configuration setting image will pop up. GPRS Bearer 1. IP Address: Proxy Server IP Address. Proxy Server can be skipped when it is not used.
  • Page 23 Playback...
  • Page 24: Playback

    Playback Playback through TV Cable connection for TV Out Please connect A/V Cable to the jack on RVS-300 / RVS-300G. Connect Yellow color A/V Output cable to Composite Video Output Terminal on TV and connect Red and White color A/V cables each to Composite Audio (Right) (Left) Output Terminal on TV.
  • Page 25: File Viewer Mode

    Playback File Viewer Mode Connect the power under the status of pressing PLAY Key and File Viewer Mode which can replay the saved files through TV-Out is started. (Green LED is blinking on operating.) 1.Press PLAY Key until Red LED is on after power connection.
  • Page 26: Playback The File Recorded On Normal Mode

    Playback Playback the file recorded on Normal Mode (Full Time) Select NORMAL FILE VIWER Select Normal File Folder Select the target file to Playback the file recorded on Event Mode Select EVENT FILE VIWER Select EVENT File...
  • Page 27: Viewer Program Installation

    Playback Playback through PC Rear View Safety RVS-300 Viewer Program installation Insert CD provided into PC and click “Next” when the below setup Wizard start image pops up. Select the folder to install the program as below image and click “Next”...
  • Page 28: Codec Installation

    Playback Codec Installation To play back the files recorded through RVS 300 Viewer program, K-Lite codec provided with a bundle CD must be installed. Double click Klcode475b.exe file on CD and start the installation. Press “Next” button when the below image pops up.
  • Page 29 Playback Codec Installation Press “Next” button when the below image pops up.. Press “Next” button when the below image pops up. When the installation is completed, the below image pops up. Then, press “Finish” button to finish the process.
  • Page 30: How To Use Viewer Program

    Playback How to use Viewer Program Double click Viewer Program Icon Viewer Program Main Screen Playback Display Slide Bar shows a play back progress and users can start play back a file on a specific part with moving it. G-Sensor Graph It shows G-Sensor data with graphs.
  • Page 31 Playback Menu Button and Control Button and Control Button and Control Function Description Description Volume Control It controls the play volume. It controls the play volume. Stop Stop playing and back to the start of the playing file. Stop playing and back to the start of the playing file. Previous Play the previous file when selects the plural files and views in series.
  • Page 32 Playback Play List Button and Control Function Description Button and Control Open Folder Selects the folder to play Deletes the selected file and G-Sensor, Delete GPS Log file which were saved together. File recorded on Selects and lists the files recorded on Normal Mode/ Normal Mode / Event Mode.
  • Page 33 Playback Playback Movie File Playback a single file 1.Select a target root folder in SD or PC with clicking Open Folder on Playback List screen. 1.Select 2.Root Folder Select 2.Select a target file to play on the file list and double click. After selecting a file on the list, Playback button can be pressed to play.
  • Page 34: Configuration Set

    Playback Configuration Set Click Configuration Set button and the below configuration image will pop up. G-Sensor Trigger Level Move the slide bar and select the value between 0.10 ~ 0.99. (Default Value: 0.50) (0.30: Sensitive, 0.50: Normal, 0.70: Dull) Audio Recording Select Voice Recording availability, ON or OFF.
  • Page 35 UPDATE...
  • Page 36: Update

    Update Firmware Update RVS-300 is firmware upgradeable through SD Card. 1. Copy the target file to update, “app.bin” into a root folder of SD Card. 2. Insert SD Card into RVS-300 / RVS-300G and connect the power. When Red, Yellow Blue LED are sequentially lit at a one second interval and JS-300 / JS-300G is started, Update is progressed with...
  • Page 37 Update SD Card Data 1. Event Folder On the Event Record Mode, RVS-300 / RVS-300G is recording the time, file name, G-Sensor Data and GPS Data and save it on the name of “evt_yyyymmdd_hhmmss.txt” when the event occurs. 2. EventMovie Folder On the Event Record Mode, RVS-300 /RVS-300G is records for the maximum 30 seconds of video and audio and save it on the name of “evt_yyyymmdd_hhmmss_1.mp4”...
  • Page 38 This Limited Warranty shall apply to the Rear View Saftey Product including all accessories as contained within the original RVS gift box (“the Product”). Rear View Safety Co., LTD. (RVS) warrants that product from its authorized distributor will meet the applicable product specifications and be free from all defects in material and workmanship for an applicable period herein (“Limited War-...
  • Page 39: Technical Support

    Others 13. THIS LIMITED WARRANTY SHALL NOT APPLY IF THE DEFECT WAS CAUSED THROUGH ANY OF THE FOLLOWING: (a) The Product serial number, the accessory date code has been removed, erased, defaced, altered or is illegible; or (b) The defect is resulting from the use of the product in a manner other than their normal and customary manner, e.g., in excess of their minimum specification or operating instructions, or malfunction or failure resulting from use of incalibrate voltages;...
