- Page 2 What’s in the Box? • 1 Color Weather Proof Backup Camera • 7" Color TFT LCD Digital Clip-On Mirror Monitor • 1-3 Channel Multiplexer Control Unit • 1-33’ Extension Cable for Camera • 1 Remote Control • 1 Power Connection Wire •...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................4 Safety Information..................5 Before Beginning Installation..............6 Installation Guide..................7 Wiring Camera & Monitor..............8-9 Installation Diagram .................10 Installation Monitor ..................11 Positioning....................Multiplexer ....................13 Monitor Dimensions..................14 Monitor Specifications................15 Camera Dimensions...................16 Camera Specifications................17 Splitting & Splicing ...................18 Troubleshooting..................19 Warranty.......................20... -
Page 4: Introduction
TV viewer or screen located for- ward of the back of the driver’s seat or in any location that is vis- ible, directly or indirectly, to the driver while operating the vehicle. REAR VIEW SAFETY... -
Page 5: Safety Information
Safety Information Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applica- ble local traffic and motor vehicle regulations as it pertains to this product. - Page 6 Dropping the unit may cause is detected, disconnect the possible mechanical failure. system immediately. • Where the power cable may touch a metal case, cover the cable with a friction tape. A short circuit or disconnected wire may cause a fire. REAR VIEW SAFETY...
- Page 7 Safety Information If you have questions about this product, contact: Customer Service: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
- Page 8 Install split grommets where applicable Step 3: Once all cables and wiring have been properly placed routed, perform a system function test by temporarily connecting he system. If the problem persists see troubleshooting (page 22). REAR VIEW SAFETY...
-
Page 9: Installation Guide
Installation Guide Camera 1. Attach camera bracket close to rear marker lights, centered on vehicle. 2. Attach camera to bracket using screws provided and adjust the angle. Cable 1. Be sure to position the cable properly. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather elements, do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts. -
Page 10: Wiring Camera & Monitor
• Camera: Drill a 20mm (0.8in) recommended to connect diameter hole into vehicle power to an ignition switched body near the camera and accessory power source. bracket. Insert camera cable REAR VIEW SAFETY... -
Page 11: Wiring Camera & Monitor
MENU Infrared technology built into 8 times and than select ON/OFF camera IRs are activated auto- Rear View Safety Pro Tips for matically according to the Sprinter lighting conditions. Chassis third brake light camera Reverse With Confidence... - Page 12 REAR VIEW SAFETY...
- Page 13 table of contents 5. Depending on your monitor choice; clip on 7 inch rear mirror moni- tor, 7 inch windshield button mount “windshield button provided” or our std 7 inch stand alone monitor, mount the monitor and then in- stall the multiplex box either under the driver seat or above behind the driver seat on the wall ceiling area 6.
-
Page 14: Installation Diagram
Installation Diagram Figure 1.1 Figure 1.2 Figure 1.3 REAR VIEW SAFETY... - Page 15 Installing the Monitor 20m Extension Cable Monitor Optional Video Out Camera Available -3 Amp Fuse 1. DC12V-24V (red) 2. Ground (black) 3. Port #3 (blue) 4. Port #2 (white) 5. Port #1 (yellow) Camera Reverse With Confidence...
- Page 16 To reset your system, press “MENU” 11 times and use arrows • To view images on other cameras, press “CAMERA SELECTION” 1 time for camera one, 2 times for camera two and 3 times for camera three. REAR VIEW SAFETY...
- Page 17 Splicing 1. Red - Power (+) 2. Yellow - Video 3. Green - Mirror / Normal Imaging 4. White - Audio 5. Black - Ground (-) Reverse With Confidence...
-
Page 18: Positioning
Positioning REAR VIEW SAFETY... -
Page 19: Multiplexer
Multiplexer Port #1 Port #2 Port #3 or DVD Backup Reverse With Confidence... -
Page 20: Monitor Dimensions
Monitor Dimensions with sun REAR VIEW SAFETY... -
Page 21: Monitor Specifications
Monitor Specifications TFT LCD Digital Monitor Screen Size Digital 7” Dot Resolution x 3 (RGB) x 480 Display Format 16:9 Display Brightness 400cd/m Viewing Angle 90° min Video Input 3 channel Video Source 1Vp-p, 75 Power Supply DC 12V-24V (+/-10%) Power Consumption Operating Temperature -10°C - +65°... -
Page 22: Camera Dimensions
Camera Dimensions REAR VIEW SAFETY... -
Page 23: Camera Specifications
Camera Specifications Camera 1/4 Color Picture Elements 250,000 pixels Gamma Correction r=0.45 to 1.0 Image Sensor 480TV lines PAL:500 / NTSC:510 x 492 Lens 2.1mm View Angle 130° Sync System Internal Synchronization Night Vision Usable Illumination 0.3 Lux Power Source DC 12V (+/-10%) S/N Ratio More than 48dB... -
Page 24: Troubleshooting
Verify Blue trigger is receiving monitor power • Verify camera is connected to cable Audio on Camera Verify chosen camera has audio Confirm that the Blue audio • • Verify volume setting trigger is connected to 12v+ • REAR VIEW SAFETY... -
Page 25: Warranty
Rear View Safety Inc. system after partial failure or use with im- proper accessories. - Page 26 In no event shall Rear View Safety and/or its affiliates have any liability for any losses (whether direct...
- Page 27 Take Notes ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ Reverse With Confidence...
- Page 28 Take Notes ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ REAR VIEW SAFETY...
- Page 29 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 BETTER CAMERAS. BETTER SERVICE. IT’S OUR GUARANTEE.
