OPERATION AND ADJUSTMENT

THE PRE-LUBRICATED WALKING BELT
Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili-
cone spray or other substances to the walking belt or the walking platform. Such substances will deterio-
rate the walking belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
This product must be earthed. If it should malfunction or break
down, earthing provides a path of least resistance for electric cur-
rent to reduce the risk of electric shock. This product is equipped
with a power cord having an equipment-earthing conductor and an
earthing plug. Important: If the power cord is damaged, it must
be replaced with a manufacturer-recommended power cord.
See drawing 1. Plug the indicated end of the power cord into the
socket on the treadmill.
See drawing 2. Press the pins on the other end of the power cord
into the indicated metal clips in the Adaptor. Close the Adaptor cover
over the end of the power cord and tighten the screw in the Adaptor.
Important: Make sure that the Adaptor cover is secure and that
the screw has been tightened before using the power cord.
See drawing 3. Plug the power cord into an appropriate outlet that is
properly installed and earthed in accordance with all local codes and
ordinances. Important: The treadmill is not compatible with
GFCI-equipped outlets.
DANGER:
Improper connection of the equipment-earthing conductor can result in an in-
creased risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as
to whether the product is properly earthed. Do not modify the plug provided with the product—if it will
not fit the outlet, have a proper outlet installed by a qualified electrician.
1
Socket on Treadmill
2
Adaptor
Screw
Cover
Pins
Adaptor
Metal
Clips
3
Outlet
10
Follow your progress with the displays.
4
See step 5 on page 12.
Measure your heart rate if desired.
5
See step 6 on page 13.
Turn on the fan if desired.
6
See step 7 on page 13.
When you are finished exercising, remove the
7
key from the console.
See step 8 on page 13.
CAUTION: Always remove iFIT.com CDs and
videocassettes from your CD player and VCR
and disconnect your MP3 player when you are
not using them.
HOW TO USE AN IFIT.COM PROGRAM
DIRECTLY FROM OUR WEB SITE
Our Web site at www.iFIT.com allows you to access
basic programs, audio programs, and video programs
directly from the internet. Additional options are soon to
be available. See www.iFIT.com for details.
To use programs from our Web site, the treadmill must
be connected to your home computer. See HOW TO
CONNECT YOUR COMPUTER on page 17. In
addition, you must have an internet connection and
an internet service provider. A list of specific system re-
quirements is found on our Web site.
Follow the steps below to use a program from our
Web site.
Insert the key into the console.
1
See HOW TO TURN ON THE POWER on page 12.
Select the iFIT.com mode.
2
To select the iFIT.com mode, press the iFIT
button. The letters "iFIT" will appear in the left dis-
play.
Go to your computer and start an internet
3
connection.
Start your web browser, if necessary, and go to
4
our Web site at www.iFIT.com.
Follow the desired links on our Web site to se-
5
lect a program.
Read and follow the on-line instructions for using a
program.
Follow the on-line instructions to start the
6
program.
When you start the program, an on-screen count-
down will begin.
Return to the treadmill and stand on the foot
7
rails. Find the clip attached to the key, and slide
the clip onto the waistband of your clothes.
When the on-screen countdown ends, the pro-
gram will begin and the walking belt will begin to
move. Hold the handrails, step onto the walking
belt, and begin walking. During the program, an
electronic "chirping" sound will alert you when the
speed and/or incline of the treadmill is about to
change. CAUTION: Always listen for the
"chirp" and be prepared for speed and/or in-
cline changes.
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, when the next "chirp" is
heard, the speed and/or incline will change to
the next settings for the program.
To stop the walking belt at any time, press the
Stop button on the console. The time will begin to
flash in the left display. To restart the program,
press the Start button or the Speed increase but-
ton. After a moment, the walking belt will begin to
move at 2 km/h. When the next "chirp" is heard,
the speed and incline will change to the next
settings of the program.
When the program is completed, the walking belt
will stop. Note: To use another program, press the
Stop button and go to step 5 on page 19.
