HOW TO USE A PRESET PROGRAM
Insert the key into the console.
1
See HOW TO TURN ON THE POWER on page
12.
Select one of the six preset programs.
2
To select one of the six preset programs, press
the Programs button repeatedly until "P1," "P2,"
"P3," "P4," "P5," or "P6" appears in the left display.
When a preset program is selected, the left dis-
play will show how long the program will last, and
a profile of the speed settings of the program will
scroll across the matrix in the display. A few sec-
onds after a preset program is selected, the maxi-
mum incline setting of the program will flash in the
display for a few seconds. In addition, the maxi-
mum speed setting of the program will flash in the
right display (not shown) for a few seconds.
Press the Start button or the Speed increase
3
button to start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each program is divided into either 30 or 50 one-
minute segments. One speed setting and one in-
cline setting are programmed for each segment.
Note: The same speed setting and/or incline setting
may be programmed for two or more consecutive
segments.
The speed setting for the first segment will be
shown in the flashing Current Segment column of
the matrix in the left display. (The incline settings
are not shown in the matrix.) The speed settings
for the next four segments will be shown in the
four columns to the right.
Current Segment
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
series of tones will sound. If the speed and/or in-
cline of the treadmill is about to change, the speed
setting and/or the incline setting will flash in the
displays to alert you.
When the first segment is completed, all speed
settings will move one column to the left . The
speed setting for the second segment will then be
shown in the flashing Current Segment column
and the treadmill will automatically adjust to the
speed and incline settings for the second seg-
ment. Note: If all five of the indicators in the
Current Segment column are lit, the speed settings
may move downward so that only the highest indi-
cators appear in the matrix.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column and the last segment
ends. The walking belt will then slow to a stop.
If the speed or incline setting for the current seg-
ment is too high or too low, you can manually
override the setting by pressing the Speed or
Incline buttons. Every few times a Speed button is
pressed, an additional indicator will appear or dis-
appear in the Current Segment column; if any of
the columns to the right of the Current Segment
column have the same number of lit indicators as
the Current Segment column, an additional indica-
tor may appear or disappear in those columns as
well. Important: When the current segment of
the program ends, the treadmill will automati-
cally adjust to the speed and incline settings
for the next segment.
To stop the program at any time, press the Stop
button. The time will begin to flash in the left dis-
play. To restart the program, press the Start button
or the Speed increase button. The walking belt will
begin to move at 2 km/h. When the next segment
of the program begins, the treadmill will automati-
cally adjust to the speed and incline settings for the
next segment.
14
Follow your progress with the displays.
4
See step 5 on page 12.
Measure your heart rate if desired.
5
See step 6 on page 13.
Turn on the fan if desired.
6
See step 7 on page 13.
When you are finished exercising, remove the
7
key from the console.
See step 8 on page 13.
HOW TO CONNECT THE TREADMILL TO USE
IFIT.COM PROGRAMS
To use iFIT.com MP3 or CD programs, the treadmill
must be connected to your MP3 player, CD player,
portable stereo, home stereo, or computer. See pages
15 and 17 for connecting instructions. To use iFIT.com
programs directly from our Web site, the treadmill
must be connected to your computer. See page 17 for
connecting instructions. To use iFIT.com video pro-
grams, the treadmill must be connected to your VCR.
See page 17 for connecting instructions.
HOW TO CONNECT YOUR MP3 PLAYER OR CD
PLAYER
A. Plug one end of the included 3.5mm to 3.5mm
stereo audio cable into the input jack on the con-
sole. Plug the other end of the cable into a jack on
your MP3 player or CD player. Plug your head-
phones into the headphone jack on the console.
A
PHONES LINE OUT
LINE OUT PHONES
Audio
Cable
Headphones
