PART LIST—Model No. PETL49905.1
To locate the parts listed below, see the EXPLODED DRAWING attached in the centre of this manual.
Key No. Qty. Description
1 2 Spring Top Cap
2 2 Isolator
3 1 Filter
4 2 Spring Bottom Cap
5 2 Spring Bracket Cover
6 2 Isolator Bolt
7 1 Latch Plate
8 2 Latch Plate Screw
9 1 Warning Decal
10 2 Rear Platform Nut
11 1 Left Rear Endcap
12 2 Roller Star Washer
13 2 Rear Roller Bolt
14 4 Roller Washer
15 4 Rear Endcap Screw
16 8 Belly Pan Screw
17 1 Rear Foot, Left
18 1 Hex Key
19 1 Right Rear Endcap
20 1 Rear Foot, Right
21 1 Frame
22 1 Rear Roller
23 2 Platform Screw, Rear
24 1 Walking Platform
25 2 Foot Rail
26 2 Foot Rail Cover
27 4 Platform Screws
28 4 Belt Guide Screw
29 2 Belt Guide
30 2 Front Isolator
31 1 5/32" Hex Key
32 1 Front Endcap, Left
33 33 3/4" Screw
34 2 Frame Pivot Bolt
35 1 Magnet
36 1 Front Roller/Pulley
37 1 Walking Belt
38 1 Front Endcap, Right
39 1 Drive Motor
40 1 Motor Belt
41 1 Motor Nut
42 2 Motor Tension Bolt
43 2 Motor Tension Washer
44 2 Motor Tension Nut
45 8 Nut
46 2 Frame Spacer
47 1 Reed Switch
48 1 Motor Bracket
49 1 Reed Switch Clip
50 1 Lift Frame
R0805A
Key No. Qty. Description
51 1 Motor Star Washer
52 17 1/2" Screw
53 1 Ground Wire
54 1 Controller
55 1 Transformer
56 1 Electronics Bracket
57 1 Bracket Grommet
58 2 Motor Mount Bolt
59 1 Motor Pivot Bolt
60 1 Incline Wire
61 2 Rear Roller Bracket
62 1 Circuit Breaker
63 1 iFIT.com Cable
64 1 Hood
65 1 Belly Pan
66 1 Releasable Tie
67 1 Belly Pan Clip
68 1 On/Off Switch
69 1 Front Roller Bolt
70 1 Power Cord Adaptor
71 1 Power Cord
72 2 Static Decal
73 1 Plastic Tie
74 1 Tie Block
75 1 Pulse Bar Plate, Left
76 4 Pulse Bar Screw
77 1 Pulse Bar
78 1 Pulse Bar Plate, Right
79 4 Cage Nut
80 1 Console Frame
81 1 Fan
82 1 Fan Cover
83 1 Receptical
84 1 Key/Clip
85 2 Caution Decal
86 2 Extension Leg
87 4 1/4" Star Washer
88 8 1/4" x 1" Bolt
89 1 Front Roller Bushing
90 1 Incline Motor Bolt, Bottom
91 1 Incline Stop Bracket
92 1 Incline Motor
93 4 Star Washer
94 2 Wheel
95 2 Wheel Bolt
96 1 Base
97 1 Left Cup Holder, Bottom
98 1 Left Cup Holder, Top
99 4 Housing Screw
100 1 Book Holder
26
IMPORTANT PRECAUTIONS
WARNING:
To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described.
3. Place the treadmill on a level surface, with at
least 2.5 m (8 ft.) of clearance behind it and
0.5 m (2 ft.) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 114 kg (250 lbs.) or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended
for both men and women. Always wear ath-
letic shoes. Never use the treadmill with bare
feet, wearing only stockings, or in sandals.
10. When connecting the power cord (see page
10), plug the power cord into an earthed cir-
cuit. No other appliance should be on the
same circuit. When replacing the fuse, an
ASTA approved BS1362 type should be fitted
to the fuse carrier. A 13 amp fuse should be
used.
11. If an extension cord is needed, use only a 3-
conductor, 1mm 2 (14-gauge) cord that is no
longer than 1.5 m (5 ft.).
12. Keep the power cord away from heated sur-
faces.
13. Never move the walking belt whilst the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See TROU-
BLESHOOTING on page 23 if the treadmill is
not working properly.)
14. Never start the treadmill whilst you are stand-
ing on the walking belt. Always hold the
handrails whilst using the treadmill.
15. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
16. Never leave the treadmill unattended whilst it
is running. Always remove the key, unplug
the power cord, and move the on/off switch to
the off position when the treadmill is not in
use. (See the drawing on page 5 for the loca-
tion of the on/off switch.)
17. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 21.)
You must be able to safely lift 20 kg (45 lbs.)
to raise, lower, or move the treadmill.
18. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
19. The pulse sensors are not medical devices.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The sensors are intended only as ex-
ercise aids in determining heart rate trends in
general.
20. When using iFIT.com programs, an electronic
"chirping" sound will alert you when the
speed and/or incline of the treadmill is about
to change. Always listen for the "chirp" and
be prepared for speed and/or incline
changes. In some instances, the speed and/or
incline may change before the personal
trainer describes the change.
3
