USER'S MANUAL
Model No. PETL49905.1
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
e-mail: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
Visit our website at
this equipment. Save this man-
ual for future reference.
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 470 Cx Treadmill and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form 470 Cx Treadmill

Summary of Contents for Pro-Form 470 Cx Treadmill

  • Page 1 USER'S MANUAL Model No. PETL49905.1 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009...

  • Page 2: Table Of Contents

    HOW TO ORDER REPLACEMENT PARTS ..........Back Cover Note: An EXPLODED DRAWING is attached in the centre of this manual. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Keep the power cord away from heated sur- that all users of this treadmill are adequately faces.
  • Page 4 21. When using iFIT.com programs, you can DANGER: Always unplug the power manually override the speed and incline set- cord immediately after use, before cleaning tings at any time by pressing the speed and the treadmill, and before performing the main- incline buttons.

  • Page 5: Before You Begin

    ® the telephone number on the front cover of this man- 470 CX treadmill. The 470 CX treadmill offers an im- ual. To help us assist you, please note the product pressive array of features to help you achieve your fit- model number and serial number before calling.

  • Page 6: Assembly

    (69)–2 ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, lubricant may be transferred to the top of the walking 1”...
  • Page 7 2. With the help of a second person, carefully lower the Uprights (96) as shown. Note: It may be helpful to place your foot on one of the Wheels (94) as you tip the Uprights. Make sure that the Extension Legs (86) re- main in the Uprights.
  • Page 8 5. See the inset drawing. Make sure that there are two U- nuts (112) in the upper end of each Upright (96). Note: Extra U-nuts may be included. Identify the right and left Handrails (108) (there is an Left identification sticker on each Handrail). Hold the right Handrail near the right Upright (96), and insert the Wire Harness (118) into the large hole in the right Handrail and out of the upper end as shown.
  • Page 9 8. With the help of another person, hold the console as- sembly near the right Upright (96) and the left Upright (not shown). Console Assembly Connect the Wire Harness (118) to the wire harness in the console assembly. Make sure to connect the con- nectors properly (see the inset drawing);...

  • Page 10: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deterio- rate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product must be earthed.
  • Page 11 CONSOLE DIAGRAM Note: If there is a sheet of clear plastic Clip on the face of the console, remove it. FEATURES OF THE CONSOLE iFIT.com MP3, CD, and video programs (iFIT.com MP3 programs, CDs, and videocassettes are available sepa- The treadmill console offers an impressive array of rately).
  • Page 12 HOW TO TURN ON THE POWER walking belt as desired by pressing the Speed increase and decrease Plug in the power cord (see page 10). buttons. Each time a button is pressed, the speed setting will Locate the on/off change by 0.1 km/h; if a button is held down, the switch near the power speed setting will change in increments of 0.5 cord.
  • Page 13 The left display will show the incline level of the the console treadmill and the elapsed time. The display will will not dis- also show your heart rate when you use the hand- play your grip pulse sensor or the optional chest pulse sen- heart rate sor.
  • Page 14 When only three seconds remain in the first seg- HOW TO USE A PRESET PROGRAM ment of the program, both the Current Segment column and the column to the right will flash and a Insert the key into the console. series of tones will sound.
  • Page 15 Follow your progress with the displays. HOW TO CONNECT THE TREADMILL TO USE IFIT.COM PROGRAMS See step 5 on page 12. Measure your heart rate if desired. To use iFIT.com MP3 or CD programs, the treadmill must be connected to your MP3 player, CD player, See step 6 on page 13.
  • Page 16 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an RCA-type AUDIO OUT Note: If your stereo has an unused LINE OUT jack, jack, see instruction A below. If your stereo has a see instruction A below.
  • Page 17 HOW TO CONNECT YOUR COMPUTER HOW TO CONNECT YOUR VCR Note: If your VCR has an unused AUDIO OUT jack, A. Plug one end of a long 3.5mm to 3.5mm stereo see instruction A below. If the AUDIO OUT jack is audio cable (available at electronics stores) into the input jack on the console.
  • Page 18 listen for the “chirp” and be prepared for speed HOW TO USE AN IFIT.COM MP3, CD, OR VIDEO and/or incline changes. In some instances, the PROGRAM speed and/or incline may change before your personal trainer describes the change. To use an iFIT.com MP3, CD, or video program, the If the speed or incline settings are too high or too treadmill must be connected to your MP3 player, CD low, you can manually override the settings at any...
  • Page 19 Follow your progress with the displays. Go to your computer and start an internet connection. See step 5 on page 12. Start your web browser, if necessary, and go to Measure your heart rate if desired. our Web site at www.iFIT.com. See step 6 on page 13.
  • Page 20 Note: If the speed and/or incline of the treadmill IMPORTANT: If a “d” appears in the right display, the does not change when a “chirp” is heard, make console is in the “demo” mode. This mode is intended sure that the letters “iFIT” appear in the left dis- to be used only when a treadmill is displayed in a store.

  • Page 21: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be permanently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill.
  • Page 22 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call the telephone number on the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 24 Locate the Reed Switch (47) and the Magnet (35) on the left side of the Pulley (36). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 3 mm (1/8 in.).

  • Page 25: Exercise Guidelines

    EXERCISE GUIDELINES is to burn fat, adjust the speed or incline of the tread- WARNING: mill until your heart rate is near the lowest number in Before beginning this your training zone. or any exercise program, consult your physi- cian. This is especially important for individu- For maximum fat burning, adjust the speed or incline als over the age of 35 or individuals with pre- of the treadmill until your heart rate is near the middle...

  • Page 26: Part List

    PART LIST—Model No. PETL49905.1 R0805A To locate the parts listed below, see the EXPLODED DRAWING attached in the centre of this manual. Key No. Qty. Description Key No. Qty. Description Spring Top Cap Motor Star Washer Isolator 1/2” Screw Filter Ground Wire Spring Bottom Cap Controller...
  • Page 27 Key No. Qty. Description Key No. Qty. Description Console 1” Tek Screw Right Cup Holder, Top Base Endcap Right Cup Holder, Bottom Base Pad Console Back Motor Bushing Access Door Fan Screw Left Handgrip, Top 5/16” Washer Left Handgrip, Bottom 4”...
  • Page 30 To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (PETL49905.1) • the NAME of the product (PROFORM 470 CX treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
